Dahua Villa VTO

错误!使用“开始”选项卡将 Heading 1 应用于要在此处显示的文字。 19
3.2.5 VTO3211D-P
VTO3211D-P installation
Table 3-4 Item list
No.
Item
No.
Item
No.
Item
1
Wall
2
Expansion bolt
3
ST3×20 screw
4
VTO cover
5
M3×6 screw
6
–
Drill screw holes on the wall according to those on the VTO, and then put the expansion
bolts in.
Connect the ports on the rear panel to those in the wall. See "2.5.2 Rear Panel."
Fix the VTO on the wall with ST3×20 screws.
Fix the VTO cover on the VTO with the M3×6 screw.
