Dahua VTO3211D-P User Manual

错误!使用“开始”选项卡将 Heading 1 应用于要在此处显示的文字。 5
No.
Name
Description
1
Fill light
Provides extra light for the camera.
2
Camera
Monitors door area.
3
Access card reader
Recognizes access card and unlock.
4
Call button
Press to call VTH or the management center.
2.2.2 Rear Panel
VTO6000CM/VTO6100C
Table 2-4 Rear panel description
No.
Name
Description
1
Ethernet port
Connects to the network with Ethernet cable.
2
Power port
Inputs 12V DC power to the VTO.
3
Debugging port
It is for engineering personnels during debugging.
4
Cable ports 1
Includes lock port, door sensor feedback port, and
exit button port. See Figure 2-8 and Figure 2-9.
5
Cable ports 2
Connecting cable (1)

Dahua VTO3211D-P Specifications

General

Brand	Dahua
Model	VTO3211D-P
Category	Intercom System
Language	English
