Dahua XVR4108C User Manual

92
Model
Parameters
HCVR4804S-S2
HCVR4808S-S2
HCVR4816S-S2
Network Video
Input
Switch 2 analog channels to the IP channels（8Mbps）
Video Output
1-ch VGA output,
1-ch HDMI output,
1-ch TV output,
HDMI/ VGA/TV video output at the same time (VGA/HDMI/TV of the
same video source)
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
4-ch,BNC port, audio via
coaxial cable
8-ch,BNC port,
audio via coaxial
cable
16-ch,BNC port,
audio via coaxial
cable
Audio Output
1-ch,BNC port
Bidirectional
Talk Input
Support（Independent bidirectional talk port）
Record
Record Mode
Auto record, manual record, motion detect record, alarm record
Record
Playback
Max 4-ch playback
Max 8-ch playback
Max 16-ch
playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
8-ch alarm input
8-ch alarm input
16-ch alarm input
Alarm Output
6-ch alarm output
HDD
HDD Port
8 SATA ports,does not support eSATA port
Space/HDD
6T
Communication
Port
Network
1 RJ45 port, 1000Mbps Ethernet port
2 RJ45 ports,
1000Mbps
Ethernet ports
Communication
1 RS232 port, 1 RS422 port, 1 RS485 port
USB
4 USB ports (Two at the front panel and two at the rear panel)
Other
Power
AC90~264V 50+2% Hz (Max 220W)
Power
Consumption
≤35W（exclude HDD）
Working
Temperature
-10℃～＋55℃
Working
Humidity
10%~90%
Dimension
2U case,440mm（W）×460mm（D）×89mm（H）
Weight
7.0kg～8.0kg（exclude HDD）
Installation
Mode
Desk/rack installation

Dahua XVR4108C Specifications

General

Brand	Dahua
Model	XVR4108C
Category	DVR
Language	English
