High definition
media interface
High definition audio and video
signal output port. It transmits
uncompressed high definition
video and multiple-channel data
to the HDMI port of the display
device.
2.2.12 HCVR5104HE/HCVR5108HE Series
The HCVR5104HE4 series rear panel is shown as below. See Figure 2- 31.
Figure 2- 31
The HCVR5108HE series rear panel is shown as below. See Figure 2- 32.
Figure 2- 32
Please refer to the following sheet for detailed information.
Connect to analog camera,
To Next Page
