Daikin 2MXM40M - System; Others

ESIE16-02B | Part 2. Troubleshooting 2.4. Component checklist
Page 58 4/04/17 | Version 1.1
RA R32 Split & multi split M-Series
2.4.3. System
Not applicable.
2.4.4. Others
Not applicable.
-9
-8
-7
-6
-5
-4
-3
-2
-1
103.18
97.73
92.61
87.79
83.25
78.97
74.94
71.14
67.56
11
12
13
14
15
16
17
18
19
37.18
35.45
33.81
32.25
30.77
29.37
28.05
26.78
25.59
31
32
33
34
35
36
37
38
39
15.10
14.48
13.88
13.31
12.77
12.25
11.76
11.29
10.84
51
52
53
54
55
56
57
58
59
6.78
6.53
6.53
6.53
6.29
6.06
5.84
5.43
5.05
71
72
73
74
75
76
77
78
79
3.32
3.21
3.11
3.01
2.91
2.82
2.72
2.64
2.55
80 2.47
T °C kΩ T °C kΩ T °C kΩ T °C kΩ T °C kΩ
