Daikin 4MXL-T Series

Specifications SiUS121827E
28 Part 2 Specifications
Model FDXS09LVJU FDXS12LVJU
Cooling Heating Cooling Heating
Power Supply Phase 1 φ 1 φ
Hz, V 60 Hz, 208 - 230 V 60 Hz, 208 - 230 V
Rated Capacity 9 kBtu/h Class 12 kBtu/h Class
External Static Pressure inAq (Pa) 0.12 (30) 0.12 (30)
Airflow Rates H
cfm
(m
3
/min)
305 (8.6) 305 (8.6) 305 (8.6) 305 (8.6)
M 280 (7.9) 280 (7.9) 280 (7.9) 280 (7.9)
L 260 (7.4) 260 (7.4) 260 (7.4) 260 (7.4)
SL 235 (6.7) 235 (6.7) 235 (6.7) 235 (6.7)
Fan Type Sirocco Fan Sirocco Fan
Motor Output W 62 62
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Filter Removable, Washable, Mildew Proof Removable, Washable, Mildew Proof
Running Current (Rated) A 0.58 - 0.52 0.58 - 0.52 0.58 - 0.52 0.58 - 0.52
Power Consumption (Rated) W 72 - 72 72 - 72 72 - 72 72 - 72
Power Factor (Rated) % 59.7 - 60.2 59.7 - 60.2 59.7 - 60.2 59.7 - 60.2
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) in. (mm) 7-7/8 × 27-9/16 × 24-7/16 (200 × 700 × 620) 7-7/8 × 27-9/16 × 24-7/16 (200 × 700 × 620)
Packaged Dimensions (H × W × D) in. (mm) 10-13/16 × 36-5/16 × 30-1/4 (274 × 923 × 768) 10-13/16 × 36-5/16 × 30-1/4 (274 × 923 × 768)
Weight (Mass) Lbs (kg) 47 (21) 47 (21)
Gross Weight (Gross Mass) Lbs (kg) 64 (29) 64 (29)
Sound Pressure
Level
H / M / L
dB(A) 35 / 33 / 31 35 / 33 / 31 35 / 33 / 31 35 / 33 / 31
Sound Power Level dB 51 51 51 51
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection Liquid in. (mm) φ 1/4 (φ 6.4) φ 1/4 (φ 6.4)
Gas in. (mm) φ 3/8 (φ 9.5) φ 3/8 (φ 9.5)
Drain in. (mm) φ 25/32 (φ 20) φ 25/32 (φ 20)
Drawing No. 3D075493 3D075494
Notes 1. SL: The quiet fan level of the airflow rate setting. 1. SL: The quiet fan level of the airflow rate setting.
Model CDXS15LVJU CDXS18LVJU
Cooling Heating Cooling Heating
Power Supply Phase 1 φ 1 φ
Hz, V 60 Hz, 208 - 230 V 60 Hz, 208 - 230 V
Rated Capacity 15 kBtu/h Class 18 kBtu/h Class
External Static Pressure inH
2
O (Pa) 0.16 (40) 0.16 (40)
Airflow Rates H
cfm
(m
3
/min)
424 (12.0) 424 (12.0) 424 (12.0) 424 (12.0)
M 388 (11.0) 388 (11.0) 388 (11.0) 388 (11.0)
L 353 (10.0) 353 (10.0) 353 (10.0) 353 (10.0)
SL 297 (8.4) 297 (8.4) 297 (8.4) 297 (8.4)
Fan Type Sirocco Fan Sirocco Fan
Motor Output W 130 130
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Filter Removable, Washable, Mildew Proof Removable, Washable, Mildew Proof
Running Current (Rated) A 0.79 0.79 0.79 0.79
Power Consumption (Rated) W 172 172 172 172
Power Factor (Rated) % 94.4 94.4 94.4 94.4
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) in. (mm) 7-7/8 × 35-7/16 × 24-7/16 (200 × 900 × 620) 7-7/8 × 35-7/16 × 24-7/16 (200 × 900 × 620)
Packaged Dimensions (H × W × D) in. (mm) 10-1/2 × 43-9/16 × 29-9/16 (266 × 1,106 × 751) 10-1/2 × 43-9/16 × 29-9/16 (266 × 1,106 × 751)
Weight (Mass) Lbs (kg) 60 (27) 60 (27)
Gross Weight (Gross Mass) Lbs (kg) 75 (34) 75 (34)
Sound Pressure
Level
H / M / L / SL
dB(A) 37 / 35 / 33 / 31 37 / 35 / 33 / 31 37 / 35 / 33 / 31 37 / 35 / 33 / 31
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection Liquid in. (mm) φ 1/4 (φ 6.4) φ 1/4 (φ 6.4)
Gas in. (mm) φ 1/2 (φ 12.7) φ 1/2 (φ 12.7)
Drain in. (mm) VP20 (O.D. φ 1-1/32 (φ 26), I.D. φ 25/32 (φ 20)) VP20 (O.D. φ 1-1/32 (φ 26), I.D. φ 25/32 (φ 20))
Drawing No. C: 3D075721 C: 3D075722
Notes 1. SL: The quiet fan level of the airflow rate setting.
2. The operating sound is based on the rear side suction
inlet and the external static pressure 0.16 inH
2
O (40 Pa).
Operating sound for bottom suction inlet : [operating
sound for rear side suction inlet] +5 dB. However, when
installation resulting in lower external static pressure
becomes low is carried out,
the operation sound may rise by more than 5 dB.
1. SL: The quiet fan level of the airflow rate setting.
2. The operating sound is based on the rear side suction
inlet and the external static pressure 0.16 inH
2
O (40 Pa).
Operating sound for bottom suction inlet : [operating
sound for rear side suction inlet] +5 dB. However, when
installation resulting in lower external static pressure
becomes low is carried out,
the operation sound may rise by more than 5 dB.
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
