SiUS121827E Specifications
Part 2 Specifications 29
Model CDXS24LVJU
Cooling Heating
Power Supply Phase 1 φ
Hz, V 60 Hz, 208 - 230 V
Rated Capacity 24 kBtu/h Class
External Static Pressure inH
2
O (Pa) 0.16 (40)
Airflow Rates H
cfm
(m
3
/min)
565 (16.0) 565 (16.0)
M 523 (14.8) 523 (14.8)
L 477 (13.5) 477 (13.5)
SL 395 (11.2) 395 (11.2)
Fan Type Sirocco Fan
Motor Output W 130
Speed Steps 5 Steps, Quiet, Auto
Air Filter Removable, Washable, Mildew Proof
Running Current (Rated) A 0.79 0.79
Power Consumption (Rated) W 160 160
Power Factor (Rated) % 90.3 92.8
Temperature Control Microcomputer Control
Dimensions (H × W × D) in. (mm) 7-7/8 × 43-5/16 × 24-7/16 (200 × 1,100 × 620)
Packaged Dimensions (H × W × D) in. (mm) 10-1/2 × 52-1/16 × 30-1/4 (266 × 1,323 × 768)
Weight (Mass) Lbs (kg) 66 (30)
Gross Weight (Gross Mass) Lbs (kg) 84 (38)
Sound Pressure
Level
H / M / L / SL
dB(A) 38 / 36 / 34 / 32 38 / 36 / 34 / 32
Heat Insulation Both Liquid and Gas Pipes
Piping Connection Liquid in. (mm) φ 1/4 (φ 6.4)
Gas in. (mm) φ 5/8 (φ 15.9)
Drain in. (mm) VP20 (O.D. φ 1-1/32 (φ 26), I.D. φ 25/32 (φ 20))
Drawing No. 3D080590
Notes 1. SL: The quiet fan level of the airflow rate setting.
2. The operating sound is based on the rear side suction inlet and the external static pressure 0.16 inH
2
O (40 Pa).
Operating sound for bottom suction inlet : [operating sound for rear side suction inlet] +5 dB.
However, when installation resulting in lower external static pressure becomes low is carried out, the operation
sound may rise by more than 5 dB.
Model FVXS09NVJU FVXS12NVJU
Cooling Heating Cooling Heating
Power Supply Phase 1 φ 1 φ
Hz, V 60 Hz, 208 - 230 V 60 Hz, 208 - 230 V
Rated Capacity 9 kBtu/h Class 12 kBtu/h Class
Front Panel Color White White
Airflow Rates H
cfm
(m
3
/min)
290 (8.2) 311 (8.8) 300 (8.5) 332 (9.4)
M 230 (6.5) 244 (6.9) 237 (6.7) 258 (7.3)
L 169 (4.8) 177 (5.0) 173 (4.9) 184 (5.2)
SL 145 (4.1) 155 (4.4) 159 (4.5) 166 (4.7)
Fan Type Turbo Fan Turbo Fan
Motor Output W 12.3 13.4
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable, Washable, Mildew Proof Removable, Washable, Mildew Proof
Running Current (Rated) A 0.14 - 0.13 0.15 - 0.14 0.14 - 0.13 0.15 - 0.14
Power Consumption (Rated) W 15 - 15 17 - 17 15 - 15 17 - 17
Power Factor (Rated) % 51.5 - 50.2 54.5 - 52.8 51.5 - 50.2 54.5 - 52.8
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) in. (mm) 23-5/8 × 27-9/16 × 8-1/4 (600 × 700 × 210) 23-5/8 × 27-9/16 × 8-1/4 (600 × 700 × 210)
Packaged Dimensions (H × W × D) in. (mm) 27-3/8 × 30-15/16 × 11 (696 × 786 × 280) 27-3/8 × 30-15/16 × 11 (696 × 786 × 280)
Weight (Mass) Lbs (kg) 31 (14) 31 (14)
Gross Weight (Gross Mass) Lbs (kg) 40 (18) 40 (18)
Sound Pressure
Level
H / M / L / SL
dB(A) 38 / 32 / 26 / 23 38 / 32 / 26 / 23 39 / 33 / 27 / 24 39 / 33 / 27 / 24
Sound Power Level dB — — — —
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection Liquid in. (mm) φ 1/4 (φ 6.4) φ 1/4 (φ 6.4)
Gas in. (mm) φ 3/8 (φ 9.5) φ 3/8 (φ 9.5)
Drain in. (mm) φ 13/16 (φ 20) φ 13/16 (φ 2 0)
Drawing No. 3D101722 3D101724
Notes 1. SL: The quiet fan level of the airflow rate setting. 1. SL: The quiet fan level of the airflow rate setting.
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
