Specifications SiUS121827E
30 Part 2 Specifications
Model FVXS15NVJU FVXS18NVJU
Cooling Heating Cooling Heating
Power Supply Phase 1 φ 1 φ
Hz, V 60 Hz, 208 - 230 V 60 Hz, 208 - 230 V
Rated Capacity 15 kBtu/h Class 18 kBtu/h Class
Front Panel Color White White
Airflow Rates H
cfm
(m
3
/min)
378 (10.7) 417 (11.8) 378 (10.7) 417 (11.8)
M 325 (9.2) 357 (10.1) 325 (9.2) 357 (10.1)
L 275 (7.8) 300 (8.5) 275 (7.8) 300 (8.5)
SL 233 (6.6) 251 (7.1) 233 (6.6) 251 (7.1)
Fan Type Turbo Fan Turbo Fan
Motor Output W 23.3 23.3
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable, Washable, Mildew Proof Removable, Washable, Mildew Proof
Running Current (Rated) A 0.19 - 0.17 0.21 - 0.19 — —
Power Consumption (Rated) W 27 - 27 34 - 34 — —
Power Factor (Rated) % 68.3 - 69.1 77.8 - 77.8 — —
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) in. (mm) 23-5/8 × 27-9/16 × 8-1/4 (600 × 700 × 210) 23-5/8 × 27-9/16 × 8-1/4 (600 × 700 × 210)
Packaged Dimensions (H × W × D) in. (mm) 27-3/8 × 30-15/16 × 11 (696 × 786 × 280) 27-3/8 × 30-15/16 × 11 (696 × 786 × 280)
Weight (Mass) Lbs (kg) 31 (14) 31 (14)
Gross Weight (Gross Mass) Lbs (kg) 40 (18) 40 (18)
Sound Pressure
Level
H / M / L / SL
dB(A) 44 / 40 / 36 / 32 45 / 40 / 36 / 32 44 / 40 / 36 / 32 45 / 40 / 36 / 32
Sound Power Level dB — — — —
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection Liquid in. (mm) φ 1/4 (φ 6.4) φ 1/4 (φ 6.4)
Gas in. (mm) φ 1/2 (φ 12.7) φ 1/2 (φ 12.7)
Drain in. (mm) φ 13/16 (φ 20) φ 13/16 (φ 20)
Drawing No. 3D101718 3D094866
Notes 1. SL: The quiet fan level of the airflow rate setting. 1. SL: The quiet fan level of the airflow rate setting.
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
