eleCTrICal daTa
Table 19: Electrical Data - Multiple Point (60/50 Hz)
NOTE: MCA = Minimum Current Ampacity, RFS = Recommended Fuse Size, MFS = Maximum Fuse Size.
For RFS, use the given values for intended standard ambient operation. If the operating ambient is intended to be above
105°F, MFS must be used.
Model
Size
Voltage /
Frequency
Multiple Point Field Data - Circuit #1 Multiple Point Field Data - Circuit #2
Ratings Lug Range Ratings Lug Range
MCA RFS MFS Power Block
Disconnect
Switch
MCA RFS MFS Power Block
Disconnect
Switch
065E
208V/60 141 175 175 (1) 14-2/0 (1) 6-350MCM 141 175 175 (1) 14-2/0 (1) 6-350MCM
230V/60 141 175 175 (1) 14-2/0 (1) 6-350MCM 141 175 175 (1) 14-2/0 (1) 6-350MCM
380V/60 85 110 110 (1) 14-2/0 (1) 4-300MCM 85 110 110 (1) 14-2/0 (1) 4-300MCM
460V/60 68 80 90 (1) 14-2/0 (1) 12-1/0 68 80 90 (1) 14-2/0 (1) 12-1/0
575V/60 59 70 80 (1) 14-2/0 (1) 12-1/0 59 70 80 (1) 14-2/0 (1) 12-1/0
400V/50 68 80 90 (1) 14-2/0 (1) 12-1/0 68 80 90 (1) 14-2/0 (1) 12-1/0
070E
208V/60 162 200 225 (1) 2-600MCM (1) 6-350MCM 162 200 225 (1) 2-600MCM (1) 6-350MCM
230V/60 162 200 225 (1) 2-600MCM (1) 6-350MCM 162 200 225 (1) 2-600MCM (1) 6-350MCM
380V/60 86 110 110 (1) 14-2/0 (1) 4-300MCM 86 110 110 (1) 14-2/0 (1) 4-300MCM
460V/60 73 90 100 (1) 14-2/0 (1) 12-1/0 73 90 100 (1) 14-2/0 (1) 4-300MCM
575V/60 62 80 80 (1) 14-2/0 (1) 12-1/0 62 80 80 (1) 14-2/0 (1) 12-1/0
400V/50 73 90 100 (1) 14-2/0 (1) 12-1/0 73 90 100 (1) 14-2/0 (1) 4-300MCM
075E
208V/60 186 225 250 (1) 2-600MCM (1) 6-350MCM 170 225 225 (1) 14-2/0 (1) 6-350MCM
230V/60 186 225 250 (1) 2-600MCM (1) 6-350MCM 170 225 225 (1) 14-2/0 (1) 6-350MCM
380V/60 92 110 125 (1) 14-2/0 (1) 4-300MCM 91 110 125 (1) 14-2/0 (1) 4-300MCM
460V/60 80 100 110 (1) 14-2/0 (1) 4-300MCM 76 100 100 (1) 14-2/0 (1) 4-300MCM
575V/60 66 80 90 (1) 14-2/0 (1) 12-1/0 65 80 90 (1) 14-2/0 (1) 12-1/0
400V/50 80 100 110 (1) 14-2/0 (1) 4-300MCM 76 100 100 (1) 14-2/0 (1) 4-300MCM
080E
208V/60 186 225 250 (1) 2-600MCM (1) 6-350MCM 186 225 250 (1) 2-600MCM (2) 3/0-500MCM
230V/60 186 225 250 (1) 2-600MCM (1) 6-350MCM 186 225 250 (1) 2-600MCM (2) 3/0-500MCM
380V/60 98 125 125 (1) 14-2/0 (1) 4-300MCM 98 125 125 (1) 14-2/0 (1) 6-350MCM
460V/60 80 100 110 (1) 14-2/0 (1) 4-300MCM 80 100 110 (1) 14-2/0 (1) 4-300MCM
575V/60 66 80 90 (1) 14-2/0 (1) 12-1/0 66 80 90 (1) 14-2/0 (1) 4-300MCM
400V/50 80 100 110 (1) 14-2/0 (1) 4-300MCM 80 100 110 (1) 14-2/0 (1) 4-300MCM
090E
208V/60 203 250 250 (1) 2-600MCM (1) 6-350MCM 203 250 250 (1) 2-600MCM (2) 3/0-500MCM
230V/60 203 250 250 (1) 2-600MCM (1) 6-350MCM 203 250 250 (1) 2-600MCM (2) 3/0-500MCM
380V/60 115 150 150 (1) 14-2/0 (1) 4-300MCM 115 150 150 (1) 14-2/0 (1) 6-350MCM
460V/60 89 110 125 (1) 14-2/0 (1) 4-300MCM 89 110 125 (1) 14-2/0 (1) 4-300MCM
575V/60 78 100 110 (1) 14-2/0 (1) 4-300MCM 78 100 110 (1) 14-2/0 (1) 4-300MCM
400V/50 89 110 125 (1) 14-2/0 (1) 4-300MCM 89 110 125 (1) 14-2/0 (1) 4-300MCM
100E
208V/60 215 300 300 (1) 2-600MCM (2) 3/0-500MCM 248 300 350 (1) 2-600MCM (2) 3/0-500MCM
230V/60 215 300 300 (1) 2-600MCM (2) 3/0-500MCM 248 300 350 (1) 2-600MCM (2) 3/0-500MCM
380V/60 129 175 175 (1) 14-2/0 (1) 6-350MCM 152 200 200 (1) 14-2/0 (2) 3/0-500MCM
460V/60 96 125 125 (1) 14-2/0 (1) 4-300MCM
117 150 150 (1) 14-2/0 (1) 6-350MCM
575V/60 87 110 110 (1) 14-2/0 (1) 4-300MCM 105 150 150 (1) 14-2/0 (1) 6-350MCM
400V/50 96 125 125 (1) 14-2/0 (1) 4-300MCM 117 150 150 (1) 14-2/0 (1) 6-350MCM
110E
208V/60 259 350 350 (1) 2-600MCM (2) 3/0-500MCM 259 350 350 (1) 2-600MCM (2) 3/0-500MCM
230V/60 259 350 350 (1) 2-600MCM (2) 3/0-500MCM 259 350 350 (1) 2-600MCM (2) 3/0-500MCM
380V/60 156 200 225 (1) 14-2/0 (1) 6-350MCM 156 200 225 (1) 14-2/0 (2) 3/0-500MCM
460V/60 120 150 175 (1) 14-2/0 (1) 6-350MCM 120 150 175 (1) 14-2/0 (1) 6-350MCM
575V/60 108 150 150 (1) 14-2/0 (1) 4-300MCM 108 150 150 (1) 14-2/0 (1) 6-350MCM
400V/50 120 150 175 (1) 14-2/0 (1) 6-350MCM 120 150 175 (1) 14-2/0 (1) 6-350MCM
