eleCTrICal daTa
www.DaikinApplied.com 41 IOM 1206-7 • TRAILBLAZER
™
MODEL AGZ CHILLERS
Table 20: Electrical Data - Multiple Point (60/50 Hz)
NOTE: MCA = Minimum Current Ampacity, RFS = Recommended Fuse Size, MFS = Maximum Fuse Size.
For RFS, use the given values for intended standard ambient operation. If the operating ambient is intended to be above
105°F, MFS must be used.
Model
Size
Voltage /
Frequency
Multiple Point Field Data - Circuit #1 Multiple Point Field Data - Circuit #2
Ratings Lug Range Ratings Lug Range
MCA RFS MFS Power Block
Disconnect
Switch
MCA RFS MFS Power Block
Disconnect
Switch
120E
208V/60 281 350 350 (1) 2-600MCM (2) 3/0-500MCM 281 350 350 (1) 2-600MCM (2) 3/0-500MCM
230V/60 281 350 350 (1) 2-600MCM (2) 3/0-500MCM 281 350 350 (1) 2-600MCM (2) 3/0-500MCM
380V/60 174 225 225 (1) 14-2/0 (1) 6-350MCM 174 225 225 (1) 14-2/0 (2) 3/0-500MCM
460V/60 137 175 175 (1) 14-2/0 (1) 6-350MCM 137 175 175 (1) 14-2/0 (1) 6-350MCM
575V/60 123 150 150 (1) 14-2/0 (1) 4-300MCM 123 150 150 (1) 14-2/0 (1) 6-350MCM
400V/50 137 175 175 (1) 14-2/0 (1) 6-350MCM 137 175 175 (1) 14-2/0 (1) 6-350MCM
130E
208V/60 281 350 350 (1) 2-600MCM (2) 3/0-500MCM 316 400 450 (1) 2-600MCM (2) 3/0-500MCM
230V/60 281 350 350 (1) 2-600MCM (2) 3/0-500MCM 316 400 450 (1) 2-600MCM (2) 3/0-500MCM
380V/60 174 225 225 (1) 14-2/0 (1) 6-350MCM 201 250 250 (1) 2-600MCM (2) 3/0-500MCM
460V/60 137 175 175 (1) 14-2/0 (1) 6-350MCM 160 200 225 (1) 14-2/0 (2) 3/0-500MCM
575V/60 123 150 150 (1) 14-2/0 (1) 4-300MCM 128 175 175 (1) 14-2/0 (1) 6-350MCM
400V/50 137 175 175 (1) 14-2/0 (1) 6-350MCM 160 200 225 (1) 14-2/0 (2) 3/0-500MCM
140E
208V/60 324 400 450 (1) 2-600MCM (2) 3/0-500MCM 324 400 450 (1) 2-600MCM (2) 3/0-500MCM
230V/60 324 400 450 (1) 2-600MCM (2) 3/0-500MCM 324 400 450 (1) 2-600MCM (2) 3/0-500MCM
380V/60 206 250 250 (1) 2-600MCM (1) 6-350MCM 206 250 250 (1) 2-600MCM (2) 3/0-500MCM
460V/60 164 200 225 (1) 14-2/0 (1) 6-350MCM 164 200 225 (1) 14-2/0 (2) 3/0-500MCM
575V/60 131 175 175 (1) 14-2/0 (1) 6-350MCM 131 175 175 (1) 14-2/0 (1) 6-350MCM
400V/50 164 200 225 (1) 14-2/0 (1) 6-350MCM 164 200 225 (1) 14-2/0 (2) 3/0-500MCM
150E
208V/60 324 400 450 (1) 2-600MCM (2) 3/0-500MCM 351 450 450 (1) 2-600MCM (2) 3/0-500MCM
230V/60 324 400 450 (1) 2-600MCM (2) 3/0-500MCM 351 450 450 (1) 2-600MCM (2) 3/0-500MCM
380V/60 206 250 250 (1) 2-600MCM (1) 6-350MCM 228 300 300 (1) 2-600MCM (2) 3/0-500MCM
460V/60 164 200 225 (1) 14-2/0 (1) 6-350MCM 182 225 250 (1) 2-600MCM (2) 3/0-500MCM
575V/60 131 175 175 (1) 14-2/0 (1) 6-350MCM 134 175 175 (1) 14-2/0 (1) 6-350MCM
400V/50 164 200 225 (1) 14-2/0 (1) 6-350MCM 182 225 250 (1) 2-600MCM (2) 3/0-500MCM
161E
208V/60 358 450 450 (1) 2-600MCM (2) 3/0-500MCM 358 450 450 (1) 2-600MCM (2) 3/0-500MCM
230V/60 358 450 450 (1) 2-600MCM (2) 3/0-500MCM 358 450 450 (1) 2-600MCM (2) 3/0-500MCM
380V/60 212 250 250 (1) 2-600MCM (1) 6-350MCM 212 250 250 (1) 2-600MCM (2) 3/0-500MCM
460V/60 165 200 200 (1) 14-2/0 (1) 6-350MCM 165 200 200 (1) 14-2/0 (2) 3/0-500MCM
575V/60 146 175 175 (1) 14-2/0 (1) 6-350MCM 146 175 175 (1) 14-2/0 (1) 6-350MCM
400V/50 165 200 200 (1) 14-2/0 (1) 6-350MCM 165 200 200 (1) 14-2/0 (2) 3/0-500MCM
170E
208V/60 358 450 450 (1) 2-600MCM (2) 3/0-500MCM 405 500 500 (1) 2-600MCM (2) 3/0-500MCM
230V/60 358 450 450 (1) 2-600MCM (2) 3/0-500MCM 405 500 500 (1) 2-600MCM (2) 3/0-500MCM
380V/60 212 250 250 (1) 2-600MCM (1) 6-350MCM 248 300 300 (1) 2-600MCM (2) 3/0-500MCM
460V/60 165 200 200 (1) 14-2/0 (1) 6-350MCM
204 250 250 (1) 2-600MCM (2) 3/0-500MCM
575V/60 146 175 175 (1) 14-2/0 (1) 6-350MCM 176 200 225 (1) 2-600MCM (1) 6-350MCM
400V/50 165 200 200 (1) 14-2/0 (1) 6-350MCM 204 250 250 (1) 2-600MCM (2) 3/0-500MCM
180E
208V/60 453 500 500 (2) 6-500MCM (2) 3/0-500MCM 453 500 500 (2) 6-500MCM (2) 3/0-500MCM
230V/60 453 500 500 (2) 6-500MCM (2) 3/0-500MCM 453 500 500 (2) 6-500MCM (2) 3/0-500MCM
380V/60 248 300 300 (1) 2-600MCM (2) 3/0-500MCM 248 300 300 (1) 2-600MCM (2) 3/0-500MCM
460V/60 204 250 250 (1) 2-600MCM (1) 6-350MCM 204 250 250 (1) 2-600MCM (2) 3/0-500MCM
575V/60 176 200 225 (1) 2-600MCM (1) 6-350MCM 176 200 225 (1) 2-600MCM (2) 3/0-500MCM
400V/50 204 250 250 (1) 2-600MCM (1) 6-350MCM 204 250 250 (1) 2-600MCM (2) 3/0-500MCM
