eleCTrICal daTa
Table 21: Electrical Data - Multiple Point (60/50 Hz)
NOTE: MCA = Minimum Current Ampacity, RFS = Recommended Fuse Size, MFS = Maximum Fuse Size.
For RFS, use the given values for intended standard ambient operation. If the operating ambient is intended to be above
105°F, MFS must be used.
Model
Size
Voltage /
Frequency
Multiple Point Field Data - Circuit #1 Multiple Point Field Data - Circuit #2
Ratings Lug Range Ratings Lug Range
MCA RFS MFS Power Block
Disconnect
Switch
MCA RFS MFS Power Block
Disconnect
Switch
190E
208V/60 413 500 500 (1) 2-600MCM (2) 3/0-500MCM 464 600 600 (2) 6-500MCM (3) 2/0-400MCM
230V/60 413 500 500 (1) 2-600MCM (2) 3/0-500MCM 464 600 600 (2) 6-500MCM (3) 2/0-400MCM
380V/60 252 300 300 (1) 2-600MCM (2) 3/0-500MCM 274 350 350 (1) 2-600MCM (2) 3/0-500MCM
460V/60 208 250 250 (1) 2-600MCM (1) 6-350MCM 231 300 300 (1) 2-600MCM (2) 3/0-500MCM
575V/60 179 225 225 (1) 2-600MCM (1) 6-350MCM 182 225 225 (1) 2-600MCM (2) 3/0-500MCM
400V/50 208 250 250 (1) 2-600MCM (1) 6-350MCM 231 300 300 (1) 2-600MCM (2) 3/0-500MCM
210E
208V/60 464 600 600 (2) 6-500MCM (2) 3/0-500MCM 464 600 600 (2) 6-500MCM (3) 2/0-400MCM
230V/60 464 600 600 (2) 6-500MCM (2) 3/0-500MCM 464 600 600 (2) 6-500MCM (3) 2/0-400MCM
380V/60 274 350 350 (1) 2-600MCM (2) 3/0-500MCM 274 350 350 (1) 2-600MCM (2) 3/0-500MCM
460V/60 231 300 300 (1) 2-600MCM (2) 3/0-500MCM 231 300 300 (1) 2-600MCM (2) 3/0-500MCM
575V/60 182 225 225 (1) 2-600MCM (2) 3/0-500MCM 182 225 225 (1) 2-600MCM (2) 3/0-500MCM
400V/50 231 300 300 (1) 2-600MCM (1) 6-350MCM 231 300 300 (1) 2-600MCM (2) 3/0-500MCM
225E
208V/60 483 600 600 (2) 6-500MCM (2) 3/0-500MCM 494 600 600 (2) 6-500MCM (3) 2/0-400MCM
230V/60 483 600 600 (2) 6-500MCM (2) 3/0-500MCM 494 600 600 (2) 6-500MCM (3) 2/0-400MCM
380V/60 278 350 350 (1) 2-600MCM (2) 3/0-500MCM 295 350 350 (1) 2-600MCM (2) 3/0-500MCM
460V/60 235 300 300 (1) 2-600MCM (2) 3/0-500MCM 253 300 300 (1) 2-600MCM (2) 3/0-500MCM
575V/60 185 225 225 (1) 2-600MCM (2) 3/0-500MCM 187 225 225 (1) 2-600MCM (2) 3/0-500MCM
400V/50 235 300 300 (1) 2-600MCM (1) 6-350MCM 253 300 300 (1) 2-600MCM (2) 3/0-500MCM
240E
208V/60 555 700 700 (2) 6-500MCM (3) 2/0-400MCM 555 700 700 (2) 6-500MCM (3) 2/0-400MCM
230V/60 555 700 700 (2) 6-500MCM (3) 2/0-400MCM 555 700 700 (2) 6-500MCM (3) 2/0-400MCM
380V/60 312 400 400 (1) 2-600MCM (2) 3/0-500MCM 312 400 400 (1) 2-600MCM (2) 3/0-500MCM
460V/60 272 300 300 (1) 2-600MCM (2) 3/0-500MCM 272 300 300 (1) 2-600MCM (2) 3/0-500MCM
575V/60 190 225 225 (1) 2-600MCM (2) 3/0-500MCM 190 225 225 (1) 2-600MCM (2) 3/0-500MCM
400V/50 272 300 300 (1) 2-600MCM (1) 6-350MCM 272 300 300 (1) 2-600MCM (2) 3/0-500MCM
