Daikin AGZ065E - Table 14: Electrical Data - Single Point (60;50 Hz)

eleCTrICal daTa
www.DaikinApplied.com 37 IOM 1206-7 • TRAILBLAZER
™
MODEL AGZ CHILLERS
Table 14: Electrical Data - Single Point (60/50 Hz) Table 15: Electrical Data - Single Point (60/50 Hz)
Model
Size
Voltage /
Freq.
Single Point Field Data
Ratings Lug Range
MCA RFS MFS Power Block
Disconnect
Switch
030E
208V/60 149 175 175 (1) 2-600MCM (1) 6-350MCM
230V/60 149 175 175 (1) 2-600MCM (1) 6-350MCM
380V/60 87 100 100 (1) 2-600MCM (1) 12-1/0
460V/60 74 80 80 (1) 14-2/0 (1) 12-1/0
575V/60 64 70 70 (1) 14-2/0 (1) 12-1/0
400V/50 77 90 90 (1) 14-2/0 (1) 12-1/0
035E
208V/60 163 175 175 (1) 2-600MCM (1) 6-350MCM
230V/60 163 175 175 (1) 2-600MCM (1) 6-350MCM
380V/60 96 110 110 (1) 2-600MCM (1) 4-300MCM
460V/60 77 90 90 (1) 14-2/0 (1) 12-1/0
575V/60 64 70 70 (1) 14-2/0 (1) 12-1/0
400V/50 80 90 90 (1) 14-2/0 (1) 12-1/0
040E
208V/60 168 200 200 (1) 2-600MCM (1) 6-350MCM
230V/60 168 200 200 (1) 2-600MCM (1) 6-350MCM
380V/60 107 125 125 (1) 2-600MCM (1) 4-300MCM
460V/60 80 90 90 (1) 14-2/0 (1) 12-1/0
575V/60 67 80 80 (1) 14-2/0 (1) 12-1/0
400V/50 83 100 100 (1) 14-2/0 (1) 12-1/0
045E
208V/60 228 250 250 (1) 2-600MCM (1) 6-350MCM
230V/60 228 250 250 (1) 2-600MCM (1) 6-350MCM
380V/60 117 125 125 (1) 2-600MCM (1) 4-300MCM
460V/60 90 100 100 (1) 2-600MCM (1) 12-1/0
575V/60 75 90 90 (1) 14-2/0 (1) 12-1/0
400V/50 94 110 110 (1) 2-600MCM (1) 4-300MCM
050E
208V/60 241 250 250 (1) 2-600MCM (2) 3/0-500MCM
230V/60 241 250 250 (1) 2-600MCM (2) 3/0-500MCM
380V/60 131 150 150 (1) 2-600MCM (1) 4-300MCM
460V/60 109 125 125 (1) 2-600MCM (1) 4-300MCM
575V/60 97 110 110 (1) 2-600MCM (1) 4-300MCM
400V/50 107 125 125 (1) 2-600MCM (1) 4-300MCM
055E
208V/60 251 300 300 (1) 2-600MCM (2) 3/0-500MCM
230V/60 251 300 300 (1) 2-600MCM (2) 3/0-500MCM
380V/60 147 175 175 (1) 2-600MCM (1) 6-350MCM
460V/60 118 125 125 (1) 2-600MCM (1) 4-300MCM
575V/60 105 125 125 (1) 2-600MCM (1) 4-300MCM
400V/50 119 125 125 (1) 2-600MCM (1) 4-300MCM
060E
208V/60 260 300 300 (1) 2-600MCM (2) 3/0-500MCM
230V/60 260 300 300 (1) 2-600MCM (2) 3/0-500MCM
380V/60 161 175 175 (1) 2-600MCM (1) 6-350MCM
460V/60 126 150 150 (1) 2-600MCM (1) 4-300MCM
575V/60 113 125 125 (1) 2-600MCM (1) 4-300MCM
400V/50 129 150 150 (1) 2-600MCM (1) 4-300MCM
NOTE: MCA = Minimum Current Ampacity, RFS = Recommended Fuse Size, MFS = Maximum Fuse Size.
For RFS, use the given values for intended standard ambient operation. If the operating ambient is intended to be above
105°F, MFS must be used.
Model
Size
Voltage /
Freq.
Single Point Field Data
Ratings Lug Range
MCA RFS MFS Power Block
Disconnect
Switch
065E
208V/60 268 300 300 (1) 2-600MCM (2) 3/0-500MCM
230V/60 268 300 300 (1) 2-600MCM (2) 3/0-500MCM
380V/60 161 175 175 (1) 2-600MCM (1) 6-350MCM
460V/60 129 150 150 (1) 2-600MCM (1) 4-300MCM
575V/60 113 125 125 (1) 2-600MCM (1) 4-300MCM
400V/50 129 150 150 (1) 2-600MCM (1) 4-300MCM
070E
208V/60 306 350 350 (1) 2-600MCM (2) 3/0-500MCM
230V/60 306 350 350 (1) 2-600MCM (2) 3/0-500MCM
380V/60 164 200 200 (1) 2-600MCM (1) 6-350MCM
460V/60 138 150 150 (1) 2-600MCM (1) 4-300MCM
575V/60 117 125 125 (1) 2-600MCM (1) 4-300MCM
400V/50 138 150 150 (1) 2-600MCM (1) 4-300MCM
075E
208V/60 338 400 400 (1) 2-600MCM (2) 3/0-500MCM
230V/60 338 400 400 (1) 2-600MCM (2) 3/0-500MCM
380V/60 173 200 200 (1) 14-2/0 (1) 6-350MCM
460V/60 149 175 175 (1) 14-2/0 (1) 6-350MCM
575V/60 125 150 150 (1) 14-2/0 (1) 4-300MCM
400V/50 149 175 175 (1) 14-2/0 (1) 6-350MCM
080E
208V/60 355 400 400 (1) 2-600MCM (2) 3/0-500MCM
230V/60 355 400 400 (1) 2-600MCM (2) 3/0-500MCM
380V/60 187 225 225 (1) 2-600MCM (1) 6-350MCM
460V/60 153 175 175 (1) 14-2/0 (1) 6-350MCM
575V/60 126 150 150 (1) 14-2/0 (1) 4-300MCM
400V/50 153 175 175 (1) 14-2/0 (1) 6-350MCM
090E
208V/60 384 450 450 (1) 2-600MCM (2) 3/0-500MCM
230V/60 384 450 450 (1) 2-600MCM (2) 3/0-500MCM
380V/60 218 250 250 (1) 2-600MCM (1) 6-350MCM
460V/60 168 200 200 (1) 14-2/0 (1) 6-350MCM
575V/60 147 175 175 (1) 14-2/0 (1) 6-350MCM
400V/50 168 200 200 (1) 14-2/0 (1) 6-350MCM
100E
208V/60 442 500 500 (2) 6-500MCM (2) 3/0-500MCM
230V/60 442 500 500 (2) 6-500MCM (2) 3/0-500MCM
380V/60 268 300 300 (1) 2-600MCM (2) 3/0-500MCM
460V/60 203 250 250 (1) 2-600MCM (1) 6-350MCM
575V/60 184 225 225 (1) 2-600MCM (1) 6-350MCM
400V/50 203 250 250 (1) 2-600MCM (1) 6-350MCM
110E
208V/60 490 600 600 (2) 6-500MCM (2) 3/0-500MCM
230V/60 490 600 600 (2) 6-500MCM (2) 3/0-500MCM
380V/60 294 350 350 (1) 2-600MCM (2) 3/0-500MCM
460V/60 227 250 250 (1) 2-600MCM (1) 6-350MCM
575V/60 204 250 250 (1) 2-600MCM (1) 6-350MCM
400V/50 227 250 250 (1) 2-600MCM (1) 6-350MCM
