IOM 1206-7 • TRAILBLAZER
™
MODEL AGZ CHILLERS 38 www.DaikinApplied.com
eleCTrICal daTa
Table 16: Electrical Data - Single Point (60/50 Hz) Table 17: Electrical Data - Single Point (60/50 Hz)
Model
Size
Voltage /
Freq.
Single Point Field Data
Ratings Lug Range
MCA RFS MFS Power Block
Disconnect
Switch
120E
208V/60 534 600 600 (2) 6-500MCM (2) 3/0-500MCM
230V/60 534 600 600 (2) 6-500MCM (2) 3/0-500MCM
380V/60 330 400 400 (1) 2-600MCM (2) 3/0-500MCM
460V/60 261 300 300 (1) 2-600MCM (2) 3/0-500MCM
575V/60 234 250 250 (1) 2-600MCM (2) 3/0-500MCM
400V/50 261 300 300 (1) 2-600MCM (2) 3/0-500MCM
130E
208V/60 569 700 700 (2) 6-500MCM (3) 2/0-400MCM
230V/60 569 700 700 (2) 6-500MCM (3) 2/0-400MCM
380V/60 358 400 450 (1) 2-600MCM (2) 3/0-500MCM
460V/60 284 350 350 (1) 2-600MCM (2) 3/0-500MCM
575V/60 239 250 250 (1) 2-600MCM (2) 3/0-500MCM
400V/50 284 350 350 (1) 2-600MCM (2) 3/0-500MCM
140E
208V/60 612 700 700 (2) 6-500MCM (3) 2/0-400MCM
230V/60 612 700 700 (2) 6-500MCM (3) 2/0-400MCM
380V/60 388 450 450 (1) 2-600MCM (2) 3/0-500MCM
460V/60 309 350 350 (1) 2-600MCM (2) 3/0-500MCM
575V/60 248 300 300 (1) 2-600MCM (2) 3/0-500MCM
400V/50 309 350 350 (1) 2-600MCM (2) 3/0-500MCM
150E
208V/60 640 700 700 (2) 6-500MCM (3) 2/0-400MCM
230V/60 640 700 700 (2) 6-500MCM (3) 2/0-400MCM
380V/60 410 500 500 (1) 2-600MCM (2) 3/0-500MCM
460V/60 328 400 400 (1) 2-600MCM (2) 3/0-500MCM
575V/60 252 300 300 (1) 2-600MCM (2) 3/0-500MCM
400V/50 328 400 400 (1) 2-600MCM (2) 3/0-500MCM
161E
208V/60 668 800 800 (2) 6-500MCM (3) 2/0-400MCM
230V/60 668 800 800 (2) 6-500MCM (3) 2/0-400MCM
380V/60 432 500 500 (1) 2-600MCM (2) 3/0-500MCM
460V/60 346 400 400 (1) 2-600MCM (2) 3/0-500MCM
575V/60 255 300 300 (1) 2-600MCM (2) 3/0-500MCM
400V/50 346 400 400 (1) 2-600MCM (2) 3/0-500MCM
170E
208V/60 734 800 800 (2) 6-500MCM (4) 4/0-500MCM
230V/60 734 800 800 (2) 6-500MCM (4) 4/0-500MCM
380V/60 442 500 500 (2) 6-500MCM (2) 3/0-500MCM
460V/60 355 400 400 (1) 2-600MCM (2) 3/0-500MCM
575V/60 309 350 350 (1) 2-600MCM (2) 3/0-500MCM
400V/50 355 400 400 (1) 2-600MCM (2) 3/0-500MCM
180E
208V/60 875 1000 1000 -- (4) 4/0-500MCM
230V/60 875 1000 1000 -- (4) 4/0-500MCM
380V/60 479 500 500 (2) 6-500MCM (2) 3/0-500MCM
460V/60 394 450 450 (1) 2-600MCM (2) 3/0-500MCM
575V/60 339 350 350 (1) 2-600MCM (2) 3/0-500MCM
400V/50 394 450 450 (1) 2-600MCM (2) 3/0-500MCM
NOTE: MCA = Minimum Current Ampacity, RFS = Recommended Fuse Size, MFS = Maximum Fuse Size.
For RFS, use the given values for intended standard ambient operation. If the operating ambient is intended to be above
105°F, MFS must be used.
Model
Size
Voltage /
Freq.
Single Point Field Data
Ratings Lug Range
MCA RFS MFS Power Block
Disconnect
Switch
190E
208V/60 848 1000 1000 (4) 2-600MCM (4) 4/0-500MCM
230V/60 848 1000 1000 (4) 2-600MCM (4) 4/0-500MCM
380V/60 508 600 600 (2) 6-500MCM (2) 3/0-500MCM
460V/60 424 500 500 (2) 6-500MCM (2) 3/0-500MCM
575V/60 348 400 400 (2) 6-500MCM (2) 3/0-500MCM
400V/50 424 500 500 (1) 2-600MCM (2) 3/0-500MCM
210E
208V/60 890 1000 1000 (4) 2-600MCM (4) 4/0-500MCM
230V/60 890 1000 1000 (4) 2-600MCM (4) 4/0-500MCM
380V/60 525 600 600 (2) 6-500MCM (2) 3/0-500MCM
460V/60 443 500 500 (2) 6-500MCM (2) 3/0-500MCM
575V/60 351 400 400 (2) 6-500MCM (2) 3/0-500MCM
400V/50 443 500 500 (1) 2-600MCM (2) 3/0-500MCM
225E
208V/60 943 1000 1000 (4) 2-600MCM (4) 4/0-500MCM
230V/60 943 1000 1000 (4) 2-600MCM (4) 4/0-500MCM
380V/60 551 600 600 (2) 6-500MCM (3) 2/0-400MCM
460V/60 469 500 500 (2) 6-500MCM (2) 3/0-500MCM
575V/60 359 400 400 (2) 6-500MCM (2) 3/0-500MCM
400V/50 469 500 500 (1) 2-600MCM (2) 3/0-500MCM
240E
208V/60 1071 1200 1200 (4) 2-600MCM (4) 4/0-500MCM
230V/60 1071 1200 1200 (4) 2-600MCM (4) 4/0-500MCM
380V/60 602 700 700 (2) 6-500MCM (3) 2/0-400MCM
460V/60 525 600 600 (2) 6-500MCM (2) 3/0-500MCM
575V/60 367 400 400 (2) 6-500MCM (2) 3/0-500MCM
400V/50 525 600 600 (1) 2-600MCM (2) 3/0-500MCM
