Daikin Altherma 3 R W Installation Manual

4 Unit installation
Installation manual
12
EBBH/X11+16DF
Daikin Altherma 3 R W
4P643600-1B – 2021.10
Table 3: Maximum chimney length
When installing a chimney, the chimney length must be less than the maximum chimney length.
• Use the columns with the correct refrigerant charge. For intermediate refrigerant charges, use the columns with the higher value. Example: If
the refrigerant charge is 4.0kg, use the columns of 5.8kg.
• For intermediate diameters, use the column with the lower value. Example: If the diameter is 23mm, use the column of 22mm.
• X: Not allowed
Maximum chimney length (m) – In case of Refrigerant charge=3.8kg (and T=60°C) In case of Refrigerant charge=5.8kg (and T=60°C)
Chimney Inside diameter of chimney (mm) Inside diameter of chimney (mm)
20 22 24 26 28 20 22 24 26 28
Straight pipe 19.03 33.90 55.16 84.54 124.06 3.37 9.47 18.40 30.91 47.91
1× 90° elbow 17.23 31.92 53.00 82.20 121.54 1.57 7.49 16.24 28.57 45.39
2× 90° elbow 15.43 29.94 50.84 79.86 119.02 X 5.51 14.08 26.23 42.87
3× 90° elbow 13.63 27.96 48.68 77.52 116.50 X 3.53 11.92 23.89 40.35
Table 4: Minimum bottom opening area for natural ventilation
Take the following into account:
• Use the correct table. For intermediate refrigerant charges, use the table with the higher value. Example: If the refrigerant charge is 4.3kg,
use the table of 4.8kg.
• For intermediate floor areas, use the column with the lower value. Example: If the floor area is 12.50m², use the column of 10.00m².
• For intermediate release height values, use the row with the lower value. Example: If the release height is 2.20m, use the row of 2.1m.
• A
nv
: Bottom opening area for natural ventilation.
• A
nv-min
: Minimum bottom opening area for natural ventilation.
• (*): Already OK (no ventilation openings needed).
A
nv-min
(dm²) – In case of Refrigerant charge=3.8kg
Release height (m) Floor area of room A (m²) [! NOT room A + room B !]
5.00 10.00 15.00 20.00 25.00 30.00 35.00
1.95 3.5 0.7 (*) (*) (*) (*) (*)
2.1 3.0 (*) (*) (*) (*) (*) (*)
2.25 2.5 (*) (*) (*) (*) (*) (*)
2.4 2.1 (*) (*) (*) (*) (*) (*)
2.55 1.7 (*) (*) (*) (*) (*) (*)
2.7 1.3 (*) (*) (*) (*) (*) (*)
2.85 1.0 (*) (*) (*) (*) (*) (*)
3 0.6 (*) (*) (*) (*) (*) (*)
A
nv-min
(dm²) – In case of Refrigerant charge=4.8kg
Release height (m) Floor area of room A (m²) [! NOT room A + room B !]
5.00 10.00 15.00 20.00 25.00 30.00 35.00
1.95 5.7 3.2 1.4 (*) (*) (*) (*)
2.1 5.2 2.5 0.4 (*) (*) (*) (*)
2.25 4.6 1.7 (*) (*) (*) (*) (*)
2.4 4.1 1.1 (*) (*) (*) (*) (*)
2.55 3.7 0.4 (*) (*) (*) (*) (*)
2.7 3.2 (*) (*) (*) (*) (*) (*)
2.85 2.8 (*) (*) (*) (*) (*) (*)
3 2.4 (*) (*) (*) (*) (*) (*)
A
nv-min
(dm²) – In case of Refrigerant charge=5.8kg
Release height (m) Floor area of room A (m²) [! NOT room A + room B !]
5.00 10.00 15.00 20.00 25.00 30.00 35.00
1.95 8.0 5.8 4.2 2.5 0.7 (*) (*)
2.1 7.3 4.9 3.1 1.3 (*) (*) (*)
2.25 6.7 4.1 2.1 0.1 (*) (*) (*)
2.4 6.1 3.3 1.2 (*) (*) (*) (*)
2.55 5.6 2.6 0.4 (*) (*) (*) (*)
2.7 5.1 2.0 (*) (*) (*) (*) (*)
2.85 4.7 1.4 (*) (*) (*) (*) (*)
3 4.2 0.8 (*) (*) (*) (*) (*)

Daikin Altherma 3 R W Specifications

General

Type	Air-to-water heat pump
Refrigerant	R-32
Energy Efficiency Class (Heating)	A+++
Energy Efficiency Class (Cooling)	A++
Operating Temperature Range (Heating)	-25°C to 35°C
Operating Temperature Range (Cooling)	10°C to 46°C
Heating Capacity	4.0 - 16.0 kW
Sound Power Level	62 dBA
