(4) Attaching the control panel
1. Remove the sealing material and prepare new replacement sealing material (accessory).
Inside view of the front grill
NOTE
• The hook positions are the same for both pre-installed cover and control panel.
2. Slide the cover to side while pushing the cover on A position from the back side and on B position from
the front side. Hooks 1 and 2 will be removed from their positions.
3. Take the cover away by pulling the left side of the cover away from the front grill, removing hooks 3a,
3b and 4 from their position.
4. Position the hook 4 on the control panel to the correct location on the front grill.
5. Attach the hooks 3a and 3b by pushing them against the front grill.
6. Slide the control panel as indicated to attach hooks 1 and 2 to their correct position.
Sealing
material
Cover
(pre-installed)
Hook 2
Hook 3a
Hook 3b
Hook 4
Hook 1
B
A
1
B
A
3
2a 2b
4 65
