Si12-411A Specifications
Specifications 31
50Hz 220-230-240V / 60Hz 220-230V
Notes:
1. The data are based on the conditions shown in the table below.
Model 3MKD75BVM 4MKD75BVM
Cooling Capacity
kW
——
Power Consumption
W
——
Running Current
A
——
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 2YC45ZXD 2YC45ZXD
Motor Output W 1,380 1,380
Refrigerant Oil
Model SUNISO 4GSD.I. SUNISO 4GSD.I.
Charge L 0.75 0.75
Refrigerant
Type R22 R22
Charge kg 2.3 2.3
Air Flow Rates
m³/min
H51 51
L45 45
cfm
H 1,472 1,472
L 1,299 1,299
Fan
Type Propeller Propeller
Motor Output W 53 53
Running Current A H: 0.33 / L: 0.25 H: 0.33 / L: 0.25
Power Consumption W H: 68 / L: 46 H: 68 / L: 46
Starting Current A 9.4 9.2
Dimensions (H×W×D) mm 735×936×300 735×936×300
Packaged Dimensions (H×W×D) mm 784×960×357 784×960×357
Weight kg 58 58
Gross Weight kg 62 62
Operation Sound dBA 48 48
Piping Connection
Liquid mm
φ
6.4
×
1,
φ
9.5
×
2
φ
6.4
×
2,
φ
9.5
×
2
Gas mm
φ
12.7
×
1,
φ
15.9
×
2
φ
12.7
×
2,
φ
15.9
×
2
Drain mm
φ
16.0
φ
16.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
No. of Wiring Connection 3 for Power Supply, 4 for Interunit Wiring 3 for Power Supply, 4 for Interunit Wiring
Max. Interunit Piping Length
m 60 (for Total of Each Room) 60 (for Total of Each Room)
m 25 (for One Room) 25 (for One Room)
Amount of Additional Charge g/m Chargeless Chargeless
Max. Installation Height Difference
m 15 (between Indoor Unit and Outdoor Unit) 15 (between Indoor Unit and Outdoor Unit)
m 7.5 (between Indoor Units) 7.5 (between Indoor Units)
Drawing No. 3D039668#1 3D039669#1
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB
5.0m
