Si18-525B Piping Diagrams
Appendix 435
FTKD25DVM FTKD35DVM
FTXS71BVMA8, FTXS71DVMT FTK50AZVMB, FTK60AZVMB, FTK71AZVMB
(
15.9CuT
)
FIELD PIPING
FIELD PIPING
(
6.4CuT
)
CROSS FLOW FAN
FAN MOTOR
(
7.9CuT
)
INDOOR UNIT
(
12.7CuT
)
M
HEAT EXCHANGER
REFRIGERANT FLOW
ON HEAT EXCH.
THERMISTOR
COOLING
HEATING
4D040082P
FIELD PIPING
FIELD PIPING
(6. 4CuT)
FTX71AZVMB
FTK71AZVMB
FTK60AZVMB
FTK50AZVMB
FTX60AZVMB
FTX50AZVMB
( CuT)
CROSS FLOW FAN
15. 9
12. 7
FAN MOTOR
(7. 9CuT)
INDOOR UNIT
(12. 7CuT)
M
HEAT EXCHANGER
REFRIGERANT FLOW
THERMISTOR
ON HEAT EXCH.
COOLING
C : 4D033700
7.9CuT
MAFFLER ASSY
CROSS FLOW FAN
FAN MOTOR
INDOOR UNIT
M
6.4CuT
6.4CuT
9.5CuT
HEAT EXCHANGER
REFRIGERANT FLOW
COOLING
6.4CuT
6.4CuT
THERMISTOR
ON HEAT EXCH.
FIELD PIPING
(6.4CuT)
FIELD PIPING
(9.5CuT)
4D051578B
7.9CuT
MAFFLER ASSY
CROSS FLOW FAN
FAN MOTOR
INDOOR UNIT
M
6.4CuT
6.4CuT
9.5CuT
HEAT EXCHANGER
REFRIGERANT FLOW
COOLING
6.4CuT
6.4CuT
THERMISTOR
ON HEAT EXCH.
FIELD PIPING
(6.4CuT)
FIELD PIPING
(12.7CuT)
4D051579B

Daikin D-Series Specifications

General

HSPF Rating	Up to 10.0
Cooling Capacity	9, 000 - 36, 000 BTU/h
Heating Capacity	9, 000 - 36, 000 BTU/h
Energy Efficiency Ratio (EER)	Up to 12.5
Sound Level	19 - 50 dB (Indoor), 49 - 60 dB (Outdoor)
Noise Level	19 - 50 dB (Indoor), 49 - 60 dB (Outdoor)
Power Supply	208/230V, 1-phase, 60Hz
