18
APPENDIX A BLOWER PERFORMANCE TABLES
DIRECT DRIVE
STANDARD DCC/DCH060 DOWN SHOT
SPEED
TAP
EXTERNAL STATIC
PRESSURE (ESP)
in w.c.
STANDARD
CFM
AMPS WATTS RPM
0.10 1334 1.65 180 627
0.20 1286 1.75 192 665
0.30 1212 1.83 202 715
0.40 1144 1.94 216 759
0.50 1077 1.99 222 792
0.60 1039 2.10 238 830
0.70 953 2.17 248 874
0.80 904 2.27 258 913
0.90 825 2.30 266 940
0.10 1512 2.12 240 682
0.20 1469 2.24 254 720
0.30 1397 2.31 264 759
0.40 1333 2.44 282 803
0.50 1285 2.54 296 836
0.60 1221 2.59 304 874
0.70 1173 2.72 322 913
0.80 1118 2.77 328 946
0.90 1049 2.90 344 984
0.10 2053 4.27 540 869
0.20 2014 4.39 558 896
0.30 1999 4.60 576 929
0.40 1947 4.68 588 957
0.50 1897 4.79 608 989
0.60 1857 4.87 620 1012
0.70 1763 4.99 640 1050
0.80 1741 5.06 650 1072
0.90 1669 5.19 668 1105
0.10 2137 4.95 634 913
0.20 2093 5.07 652 940
0.30 2095 5.19 670 962
0.40 2026 5.28 682 990
0.50 1980 5.40 698 1018
0.60 1961 5.49 720 1039
0.70 1914 5.58 732 1072
0.80 1845 5.70 742 1100
0.90 1766 5.69 740 1127
0.10 2299 5.70 742 942
0.20 2233 5.80 748 969
0.30 2217 5.90 768 990
0.40 2157 6.07 786 1018
0.50 2131 6.12 804 1045
0.60 2060 6.21 816 1073
0.70 2015 6.30 820 1095
0.80 1940 6.27 816 1111
0.90 1862 6.13 790 1128
NOTES:
T5
DCC/DCH060 DIRECT DRIVE DOWN SHOT
Tables represent dry coil without filter, to compensate for filter add 0.08" to measured E.S.P. SCFM correction for wet coil = 4
%. 5 Ton models are shipped from the factory with speed tap set on T4.
T1
T2
T3
T4
