Daikin DCH072 SERIES Installation Instructions

16
APPENDIX A BLOWER PERFORMANCE TABLES
DIRECT DRIVE
STANDARD DOWN SHOT AND HORIZONTAL
SPEED TAP
EXTERNAL STATIC
PRESSURE (ESP)
in w.c.
STANDARD
CFM
AMPS WATTS RPM
0.10 1287 1.66 350 770
0.20 1233 1.63 342 815
0.30 1176 1.59 332 858
0.40 1107 1.55 320 891
0.50 1044 1.51 312 924
0.60 965 1.45 296 957
0.10 1476 2.08 446 866
0.20 1421 2.03 432 885
0.30 1334 1.96 414 918
0.40 1255 1.90 396 945
0.50 1180 1.84 386 971
0.60 1085 1.78 368 990
0.70 964 1.70 344 1023
0.30 1455 2.31 490 962
0.40 1367 2.25 476 984
0.50 1277 2.16 454 1006
0.60 1180 2.09 438 1025
0.70 1080 2.02 418 1039
0.80 922 1.90 386 1067
SPEED TAP
EXTERNAL STATIC
PRESSURE (ESP)
in w.c.
STANDARD
CFM
AMPS WATTS RPM
0.10 1296 1.67 356 764
0.20 1245 1.60 334 830
0.30 1174 1.56 325 861
0.40 1103 1.52 316 891
0.50 1013 1.46 300 935
0.10 1502 2.10 456 836
0.20 1449 2.06 444 864
0.30 1396 2.02 432 891
0.40 1335 1.97 418 916
0.50 1273 1.91 404 940
0.60 1153 1.83 380 973
0.70 996 1.71 346 1017
0.20 1516 2.36 506 940
0.30 1454 2.31 496 960
0.40 1392 2.26 486 979
0.50 1273 2.17 458 1006
0.60 1183 2.09 441 1023
0.70 1092 2.02 424 1039
0.80 920 1.90 390 1067
NOTES:
3 Ton models are shipped from the factory with speed tap set on LOW.
Tables represent dry coil without filter, to compensate for filter add 0.08" to measured E.S.P. SCFM correction for
wet coil = 4 %.
DCC/DCH036 DIRECT DRIVE HORIZONTAL
LOW
HIGH
MED
HIGH
DCC/DCH036 DIRECT DRIVE DOWN SHOT
LOW
MED
