Daikin DCH072 SERIES Installation Instructions

26
APPENDIX C UNIT DIMENSIONS
HORIZONTAL DISCHARGE
VERTICAL DISCHARGE
RETURN
SUPPLY
12”
17” 7 3/8”
11”
25”
6 1/4”
4 7/8”
DRAIN
THRU CURB
LOCATION
EMBOSS
FOR
THRU THE
BASE
UTILITIES
BOTTOM VIEW OF UNIT
8 3/16”
5 7/8”
19 7/16”
27 3/8”
47 1/2”
4 1/2”
7 1/2”
SUPPLY
RETURN
73 1/4”
47 1/2”
74 1/16”
48 3/16”
38 13/16”*
*6 Ton - 42 13/16
NOTE: Refer to IOD-7006 included in the literature pack for installing horizontal duct covers.
