Daikin DCH072 SERIES Installation Instructions

20
APPENDIX A BLOWER PERFORMANCE TABLES
BELT DRIVE
STANDARD DOWN SHOT
DCC/DCH036 STANDARD BELT DRIVE DOWN SHOT
CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP
0.2
1424 0.30 1239 0.23
0.4
1520 0.39 1292 0.29 1073 0.22 779 0.14
0.6 1439 0.40 1192 0.30 944 0.21 619 0.12
0.8 1350 0.42 1101 0.31 864 0.22
1.0 1028 0.31 729 0.21
1.2 675 0.20
DCC/DCH048 STANDARD BELT DRIVE DOWN SHOT
CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP
0.2
2129 0.64 1795 0.47 1550 0.35
0.4
1994 0.65 1701 0.49 1433 0.36 1163 0.22
0.6 1905 0.67 1606 0.50 1326 0.36 1025 0.22
0.8 1808 0.69 1565 0.54 1216 0.36
1.0 1473 0.55 1137 0.32
1.2 1103 0.41
DCC/DCH060 STANDARD BELT DRIVE DOWN SHOT
CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP
0.2
2579 1.01 2368 0.85 2175 0.69 1961 0.55
0.4
2513 1.05 2318 0.89 2089 0.73 1906 0.59 1666 0.44
0.6 2514 1.14 2276 0.94 2045 0.77 1797 0.60 1604 0.47
0.8 2261 1.01 2017 0.82 1760 0.63
1.0 1989 0.87 1730 0.68
1.2 1695 0.72
DCC/DCH072 STANDARD BELT DRIVE DOWN SHOT (INCLUDES 2 SPEED MOTOR AT HIGH SPEED)
CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP
0.2
2771 1.27 2567 1.05 2421 0.88 2220 0.71
0.4
2753 1.38 2573 1.15 2382 0.95 2186 0.77 1980 0.61
0.6 2655 1.42 2548 1.24 2360 1.02 2119 0.81 1934 0.65
0.8 2470 1.30 2331 1.11 2111 0.89 1868 0.69
1.0 2296 1.18 2078 0.96 1840 0.75
1.2 2040 1.02
NOTES:
ESP, In
H
2
O
TURNS OPEN
012345
Tables represent dry coil without filter, to compensate for filter add 0.08" to measured E.S.P.
SCFM correction for wet coil = 4 %.
ESP, In
H
2
O
TURNS OPEN
012345
ESP, In
H
2
O
TURNS OPEN
012345
ESP, In
H
2
O
TURNS OPEN
012345
