Daikin DCH072 SERIES Installation Instructions

23
APPENDIX A BLOWER PERFORMANCE TABLES
BELT DRIVE
HIGH STATIC HORIZONTAL
DCC/H036 HIGH STATIC BELT DRIVE HORIZONTAL
CFMBHPCFMBHPCFMBHPCFMBHPCFMBHPCFMBHP
0.6 1742 0.50 1431 0.36
0.8 1626 0.52 1357 0.39 1078 0.27
1.0 1611 0.56 1315 0.42 1011 0.28
1.2 1605 0.62 1299 0.46 976 0.31
1.4 1605 0.68 1281 0.51 959 0.36
1.6 1281 0.57 981 0.41
1.8 981 0.47
DCC/H048 HIGH STATIC BELT DRIVE HORIZONTAL
CFMBHPCFMBHPCFMBHPCFMBHPCFMBHPCFMBHP
0.6 2056 0.72 1721 0.54
0.8 1996 0.77 1662 0.57 1328 0.40
1.0 1924 0.79 1603 0.61 1270 0.43
1.2 1952 0.88 1559 0.64 1210 0.44
1.4 1888 0.92 1573 0.70 1195 0.49
1.6 1557 0.77 1180 0.54
1.8 1192 0.60
DCC/H060 HIGH STATIC BELT DRIVE HORIZONTAL
CFMBHPCFMBHPCFMBHPCFMBHPCFMBHPCFMBHP
0.6 2323 0.92
0.8 2315 1.00 2009 0.77
1.0 2308 1.09 1992 0.84 1666 0.60
1.2 2338 1.21 1992 0.92 1646 0.66
1.4 2359 1.32 2025 1.02 1648 0.72
1.6 2404 1.45 2053 1.13 1684 0.82
1.8 2088 1.24 1722 0.92
DCC/H072 HIGH STATIC BELT DRIVE HORIZONTAL (INCLUDES 2 SPEED MOTOR ON HIGH SPEED)
CFMBHPCFMBHPCFMBHPCFMBHPCFMBHPCFMBHP
0.6
2746 1.38 2515 1.12
0.8
2721 1.47 2494 1.21 2261 0.97
1.0 2689 1.56 2500 1.32 2255 1.06 1994 0.83
1.2 2752 1.74 2473 1.40 2252 1.15 1996 0.91
1.4 2802 1.88 2487 1.53 2286 1.27 2037 1.02
1.6 2553 1.67 2308 1.40 1997 1.08
1.8 2355 1.51 2014 1.19
2 2055 1.29
NOTES:
Tables represent dry coil without filter, to compensate for filter add 0.08" to measured E.S.P. SCFM
correction for wet coil = 4 %.
ESP, In
H
2
O
TURNS OPEN
012345
ESP, In
H
2
O
TURNS OPEN
012345
ESP, In
H
2
O
TURNS OPEN
012345
ESP, In
H
2
O
TURNS OPEN
012345
