opTIonal eleCTrIC heaT
Electric Heater Design
If the 10th digit in the model number is an “E”, the rooftop
unit was furnished with a factory installed electric furnace
(Example, DPS010AHCE). The Rebel rooftop units are
available with 4-stage heat output (see capacities in Table 23.
This packaged electric heat rooftop unit is designed for outdoor
non-residential installations only.
The electric heat design consists of a heating coil, DDC staging
control, and all operational safeties. The safety switches include
high-limit temperature switches and individual coil fusing.
The high limit switch is an automatic reset switch. It opens the
control circuit and shuts the heater down when the temperature
reaches the high limit switch closes again allows the heater
to run when the temperature gets below dead band. There is
a second level of protection with an auxiliary high limit switch.
This switch opens up and shuts the heater down when the
temperature exceeds the set point. This switch requires a
manual reset.
Electric Heating Capacity Data
Table 13: Heating Capacity – Electric Heaters
Unit Stages
Option # 1 Option # 2 Option # 3 Option # 4 Option # 5 Option # 6
KW MBH
Delta
T
1
Min
(cfm)
KW MBH
Delta
T
1
Min
(cfm)
KW MBH
Delta
T
1
Min
(cfm)
KW MBH
Delta
T
1
Min
(cfm)
KW MBH
Delta
T
1
Min
(cfm)
KW MBH
Delta
T
1
Min
(cfm)
003
2,
SCR
6 20.5
15.8
316 12 40.9
31.6
632 18 61.4
47.4
948 30 102.4
60.0
3
1580
— — — — — — — —
004 11.9 23.7 35.6 59.3 — — — — — — — —
005 9.5 19.0 28.4 47.4 — — — — — — — —
006 7.9 15.8 23.7 39.5 — — — — — — — —
007
4,
SCR
18 61.4
19.0
948 36 122.9
37.9
1896 54 184.3
56.9
2844 72.0
2
245.8
60.0
3
3793
— — — — — — — —
010 14.2 28.4 42.7 56.9 — — — — — — — —
012 11.9 23.7 35.6 47.4 — — — — — — — —
015 9.5 19.0 28.4 37.9 — — — — — — — —
016
30 102
17.5
1580 45 154
26.2
2369 60 205
34.9
3159 90 307
52.4
4739
— — — — — — — —
018
020 13.5 20.3 27.1 40.6
120 409
54.2
6319
— — — —
025 10.8 16.2 21.7 32.5 43.3
150 512
54.2
7898
028 9.8 14.8 19.7 29.5 39.4 49.2
NOTE: 1. Temperature is calculated at nominal air ow
NOTE: 2. Not available in 208 & 230 Volt
NOTE: 3. 60 degree max rise
opTIonal eleCTrIC heaT
www.DaikinApplied.com 39 IM 1125-7 • REBEL ROOFTOPS
