Daikin DV25PECB14 - Electric Heat; Heat Kit Selection

10
3 5 6 8
10 15 19/20 25
800 12 19 23 31 37
1000 9
15 19 25 30 44
1200 8 12 15 21 25 37 49 62
1400 7 11 13 18 21 32 42 53
1600 6
9 12 15 19 28 37 46
1800 5 8 10 14 16 25 33 41
2000 5 7 9 12 15 22 30 31
240/1/60 SUPPLY VOLTAGE - TEMP. RISE °F
Table 4
CFM
HEAT KIT NOMINAL Kw
3 5 6 8 10 15 19/20 25
800 11 18 22 30 35
1000 9 14 18 24 28 42
1200 7 12 15 20 24 35 47 59
1400 6 10 13 17 20 30 40 51
1600 6 9 11 15 18 27 35 44
1800 5 8 10 13 16 24 31 39
2000 4 7 9 12 14 21 28 35
CFM
HEAT KIT NOMINAL Kw
230/1/60 SUPPLY VOLTAGE - TEMP. RISE °F
Table 5
3 5 6 8 10 15 19/20 25
800 10 17 21 28 33
1000 8 13 17 22 27 40
1200 7 11 14 19 22 33 45 56
1400 6 10 12 16 19 29 38 48
1600 5 8 10 14 17 25 33 42
1800 5 7 9 12 15 22 30 37
2000 4 7 8 11 13 20 27 33
208/1/60 SUPPLY VOLTAGE - TEMP. RISE °F
Table 6
CFM
HEAT KIT NOMINAL Kw
Air Handler
3" MIN.
POSITIVE LIQUID
SEAL REQUIRED
AT TRAP
Drain
Connection
2" MIN.
Figure 12
Transformer
Sub-Assembly
I
n
s
t
a
l
l
U
n
i
n
s
t
a
l
l
Figure 13
MINI MUM CFM REQUIRED FOR HEATERKI TS
Table 6
Model
HEATER (kW)
3 5 6 8 10 15 19 20 25
DV25PECB14 550 650 700 715 875
DV24FECB14 550 650 700 715 875
DV36fECC14 850 900
1000
1120
122
0
1250
DV37FECC14 850 900
1000
1120
122
0
1250
DV42FECC14 850 900
1000
1120
122
0
1250
DV48FECD14 990
1110
1200
1240
152
0
1520
DV59PECD14 990
1110
1200
1240
152
0
1520
DV60FECD14
1030
1150
1250
1320
165
0
1690
1715
DV61PECD14
1030
1150
1250
1320
165
0
1690
1715
Table 7
