18 System configuration
18.1 Independent system
a
b
VAMEKVDX
P1 P2
P1 P2
b
VAMEKVDX
P1 P2
F1 F2P1 P2F1 F2
P1 P2F1 F2P1 P2F1 F2
b
P1 P2
F1 F2
VRV
P1
P2
a Outdoor unit
b Controller
VRV VRV indoor unit
EKVDX EKVDX indoor unit
VAM VAM heat reclaim ventilation unit
NOTICE
Group control connection is NOT allowed.
