TECHNICAL SPECIFICATIONS
INDOOR UNITS FAQ71BUV1B FAQ100BUV1B
DIMENSIONS Unit H mm 290 360
W mm 1,050 1,570
D mm 230 200
WEIGHT Unit kg 13 26
MATERIAL Unit Resin
COLOUR Unit White
SOUND LEVEL
Sound pressure (cooling/heating) (4)
high dB(A) 43/43 45/45
low dB(A) 37/37 41/41
Sound power (cooling/heating) (5)
high dB(A) 59/59 61/61
low dB(A) 53/53 57/57
FAN Air flow rate high m
3
/min 19/19 23/23
low m
3
/min 15/15 19/19
Speed steps 2 steps
Type Cross flow fan
Qty x motor output W 1 x 43 1 x 49
HEAT EXCHANGER Type Cross fin coil (Multi louver fins and Hi-XA tubes)
Rows x stages x fin pitch mm 2 x 16 x 1.4 2 x 12 x 1.4
Face area m
2
0.289 0.332
PIPING CONNECTIONS liquid mm φ9.5 (flare)
gas mm φ15.9 (flare)
drain I.D. mm φ13 (VP13) φ20 (VP20)
drain O.D. mm φ18 (VP13) φ26 (VP20)
INSULATION MATERIAL Heat insulation Foamed polystyrene/foamed polyethylene
For outdoor units
Pair / Twin / Triple application See chapter RR-B / RQ-B / RZQ-B
•
Wall Mounted, Inverter Controlled Unit • R-410A • FAQ71-100BUV1B
