Daikin FAQ71BUV1B User Manual

4 Piping diagrams
O Check valve L Flare connection M Screw connection N Flange connection Z Pinched pipe P Spinned pipe
Indoor heat exchanger
Field piping J9.5 C1220T-0
4D037995A
FAQ71-100BUV1B
Field piping J15.9 C1220T-0
Refrigerant pipe connection port diameters
Model A B
FAQ71, 100BUV1B J 9.5 J 15.9
To outdoor unit
Indoor unit
• Wall Mounted, Inverter Controlled Unit • R-410A • FAQ71-100BUV1B
