ESIE05-04 General Outline
Part 1 – System Outline 1–9
3
1
4
5
Components The table below contains the different components of the unit.
No. Component
1 Liquid pipe connection
2 Gas pipe connection
3 Drain pipe connection
4 Power supply / Wiring / Remote controller connection
5 Air outlet
6 Suction grille
7 Corner decoration cover
8 Drain hose (accessory)
