SiK401004_A
111 MAINTENANCE
6. Installation of new
right (back) panel
●Put new right (back) panel into right
position.
●Screw down the surrounding
retaining screws with screwdriver.
7. Installation of new
panel (external
casing)
●Put new panel (external casing) into
right position on the unit;
●Screw down the surrounding
retaining screws with screwdriver.
●Some models (R(Y)30PEV1K;
R(Y)36PEV1K; R(Y)42PEV1K;
R(Y)48TPEV1K) need to be equipped
with front panel outside the external
casing
8. Installation of front
grill
●Put new front grill into correct position
on the unit
●Screw down the surrounding
retaining screws with screwdriver.
9. Installation of new
rear grill
●Put new rear grill into the right
position on the unit
●Screw down the surrounding
retaining screws with screwdriver.
10. Installation of new
top cover
●Put the new top cover into the correct
position on the unit
●Screw down the surrounding
retaining screws with screwdriver
To Next Page
