SiK401004_A
SPECIFICATIONS 6
4. PRODUCT DATA
4.1 Product Data at Rated Condition
4.1.1 Duct Type
Outdoor R24PEV1K
Model
Indoor FDM24PEV1K
Function ― COOLING
Rated Voltage ― 220-240V 1Ph
Rated Frequency ― 50Hz
Total Capacity (Btu/h)/W
6800
23200
Power Input W 2500
Rated Current A 11.9
Max Current A 19.0
Air Flow Volume (H/M/L)**
m
3
/h
1600/1400/1200
ESP Pa 25
EER (Btu/h)/W 9.28
Indoor Unit FDM24PEV1K
Fan Motor Speed (H/M/L) r/min 1250/1220/1060
Output of Fan Motor W 150
Fan Motor Capacitor µF 8
Fan Type-Piece ― Centrifugal fan – 2
Diameter-Length mm φ160 – 200
Evaporator ― Aluminum fin-copper tube
Pipe Diameter mm φ9.52
Row-Fin Gap mm 2-1.8
Coil length (L) x height (H) x coil width (W) mm 1002X253X44
Fuse A 5
Sound Pressure Level dB (H/M/L) A 47/44/42
Sound Power Level dB (H/M/L) A 57/54/52
Dimension (W/H/D) mm 1270/268/530
Dimension of Package (W/H/D) mm 1345/283/594
Indoor
unit
Net Weight/Gross Weight kg 36/42
To Next Page
