Engineering & Physical Data
Engineering & Physical Data
Engineering Data - R22 MODEL
MODEL
INDOOR UNIT FF10CXV1 FF15CXV1 FF20CXV1
OUTDOOR UNIT R10CXV1 R15CXV1 R20CXV1
NOMINAL COOLING CAPACITY
Btu/h 9500 12500 19000
W 2780 3660 5570
NOMINAL TOTAL INPUT POWER (COOLING) W 920 1206 1832
NOMINAL RUNNING CURRENT (COOLING) A 4.10 5.30 8.10
EER W/W 3.03 3.04 3.04
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAPILLARY TUBE
REFRIGERANT CHARGE kg 0.63 0.75 1.35
MODEL
INDOOR UNIT FFY10CXV1 FFY15CXV1 FFY20CXV1
OUTDOOR UNIT RY10CXV1 RY15CXV1 RY18CXV1 RY20CXV1
NOMINAL COOLING CAPACITY
Btu/h 9500 12500 18000 19000
W 2780 3660 5280 5570
NOMINAL HEATING CAPACITY
Btu/h 9500 12500 18400 19500
W 2780 3660 5390 5720
NOMINAL TOTAL INPUT POWER (COOLING) W 920 1206 1840 1832
NOMINAL TOTAL INPUT POWER (HEATING) W 820 1056 1680 1782
NOMINAL RUNNING CURRENT (COOLING) A 4.10 5.30 8.20 8.10
NOMINAL RUNNING CURRENT (HEATING) A 3.60 4.70 7.50 7.90
EER W/W 3.03 3.04 2.87 3.04
COP W/W 3.40 3.47 3.21 3.21
REFRIGERANT CONTROL (EXPANSION DEVICE) OUTDOOR CAPILLARY TUBE
REFRIGERANT CHARGE kg 0.63 0.93 0.85 1.35
POWER SOURCE V/Ph/Hz 220 - 240 / 1/ 50
REFRIGERANT TYPE R22
INDOOR UNIT
CONTROL
AIR DISCHARGE 4 WAY AUTOMATIC LOUVER (UP & DOWN)
OPERATION WIRELESS MICROCOMPUTER REMOTE CONTROL
AIR FLOW
HIGH l/s / CFM 194 / 410 194 / 410 212 / 450
MEDIUM l/s / CFM 170 / 360 170 / 360 194 / 410
LOW l/s / CFM 156 / 330 156 / 330 160 / 340
SOUND PRESSURE LEVEL (H/M/L) dBA 41 / 38 / 35 41 / 38 / 34 44 / 41 / 37
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 250 X 570 X 570
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 317 X 630 X 630
UNIT WEIGHT (UNIT + PANEL) kg 22 + 2 23 + 2
CONDENSATE DRAIN SIZE mm 19.05
FAN
TYPE TURBO
DRIVE DIRECT
FAN MOTOR
TYPE INDUCTION
INDEX OF PROTECTION (IP) IP20
INSULATION GRADE CLASS B
RATED INPUT POWER W 55 65 59
RATED RUNNING CURRENT A 0.24 0.29 0.25
MOTOR OUTPUT W 19 23 28
POLES 6
COIL
TUBE
MATERIAL COPPER
DIAMETER mm 7
FIN
MATERIAL ALUMINIUM
FACE AREA m
2
0.318
ROW 12
AIR QUALITY FILTER
TYPE WASHABLE SARANET FILTER
QUANTITY pc 1
CASING COLOUR WITHOUT PAINT
OUTDOOR UNIT
AIR FLOW l/s / CFM 453 / 960 614 / 1300
SOUND PRESSURE LEVEL dBA 46 49 51
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm 540 X 700 X 250 651 X 855 X 328
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm 620 X 810 X 330 710 X 990 X 415
UNIT WEIGHT (R / RY) kg 28 / 30 43 47
PIPE
CONNECTION
TYPE FLARE VALVE
SIZE
LIQUID mm 6.35
GAS mm 9.52 12.7 15.88
FAN
TYPE PROPELLER
DRIVE DIRECT
FAN MOTOR
TYPE INDUCTION
INDEX OF PROTECTION (IP) IP23
INSULATION GRADE CLASS B CLASS F
RATED INPUT POWER W 57 76 81 80
RATED RUNNING CURRENT A 0.25 0.33 0.36 0.36
MOTOR OUTPUT W 21 30 32 32
POLES 6
COMPRESSOR
TYPE ROTARY
OIL TYPE ATMOS NM56M or SUNISO 4GDID
OIL AMOUNT cm
3
320 350 670
R RATED INPUT POWER W 808 1065 1692 1693
RY
RATED INPUT POWER (COOLING) W 808 1065 1700 1693
RATED INPUT POWER (HEATING) W 708 915 1540 1643
R RATED INPUT CURRENT A 3.61 4.68 7.49 7.49
RY
RATED INPUT CURRENT (COOLING)
A 3.61 4.68 7.59 7.49
RATED INPUT CURRENT (HEATING)
A 3.11 4.08 6.89 7.29
LOCKED ROTOR AMP. A 20 25 34 34
COIL
TUBE
MATERIAL COPPER
DIAMETER (R / RY) mm 7 7 / 9.52 7
FIN
MATERIAL ALUMINIUM
FACE AREA m
2
0.36 0.52
ROW 12
CASING COLOUR LIGHT GREY
ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
COOLING HEATING
INDOOR: 27°C DB/ 19°C WB INDOOR: 20°C DB
OUTDOOR: 35°C DB/ 24°C WB OUTDOOR: 7°C DB/ 6°C WB
