Daikin FF-C - R22 Model Safety Devices

24
Engineering & Physical Data
Safety Device
R22
MODEL
INDOOR FF(Y)10/15EXV1 FF(Y)20CXV1
OUTDOOR R(Y)10/15CXV1 RY18CXV1 R(Y)20CXV1
SAFETY
DEVICE
HIGH PRESSURE
SWITCH
TYPE N/A
OPEN kPa / psi N/A
CLOSE kPa / psi N/A
LOW PRESSURE
SWITCH
TYPE N/A
OPEN kPa / psi N/A
CLOSE kPa / psi N/A
PHASE SEQUENCER N/A
DISC. THERMOSTAT SETTING °C / F N/A
MODEL
INDOOR FH(Y)C20/25/28EXV1
OUTDOOR R(Y)20/25/28CXV1
SAFETY
DEVICE
HIGH PRESSURE
SWITCH
TYPE N/A
OPEN kPa / psi N/A
CLOSE kPa / psi N/A
LOW PRESSURE
SWITCH
TYPE N/A
OPEN kPa / psi N/A
CLOSE kPa / psi N/A
PHASE SEQUENCER N/A
DISC. THERMOSTAT SETTING °C / F N/A
MODEL
INDOOR FHC40EXV1
OUTDOOR R35DXV1 R40DXV1 R40DXY1
SAFETY
DEVICE
HIGH PRESSURE
SWITCH
TYPE NC
OPEN kPa / psi 2937 / 426
CLOSE kPa / psi 2413 / 350
LOW PRESSURE
SWITCH
TYPE NC
OPEN kPa / psi 124 / 18
CLOSE kPa / psi 192 / 28
PHASE SEQUENCER N/A YES
DISC. THERMOSTAT SETTING °C / F N/A N/A 130 / 266
MODEL
INDOOR FHC50EXV1
OUTDOOR R50DXY1
SAFETY
DEVICE
HIGH PRESSURE
SWITCH
TYPE NC
OPEN kPa / psi 2937 / 426
CLOSE kPa / psi 2413 / 350
LOW PRESSURE
SWITCH
TYPE NC
OPEN kPa / psi 124 / 18
CLOSE kPa / psi 192 / 28
PHASE SEQUENCER YES
DISC. THERMOSTAT SETTING °C / F 130 / 266
ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
