Daikin FF-C - Outline & Dimension

49
Outline & Dimension
Outline & Dimension
Indoor Unit
Model: FF(Y)10/15/20CXV1
Note: Dimension in mm
Model: FH(Y)C20/25/28/40/50EXV1
A
B
C
D
E
F
H
K
J
I
G
Dimension
Model
ABCDEFGH I JK
FH(Y)C20/25/28EXV1 820 820 340 300 40 990 990 627 627 607 430
FH(Y)C40/50EXV1 820 820 375 335 40 990 990 627 627 607 430
Note: Dimension in mm
