Daikin FMA50RVMA - Names of Parts

Indoor Unit
a
b
c
d
e
f
g
h
i
j
k
l
m
a Draindischargedevice(built-in) g Refrigerantpiping
b Drainpaninspectionwindow h Drainpiping
c
Remotecontroller(Wiredtype)
Theappearanceoftheremotecontrollermaydifferbetween
differentmodels.
i Modelname(Modelnameplate)
j Airfilter(Soldseparately)
k Suctionfilterchamber(Soldseparately)
d Wiringbetweentheindoorandoutdoorunits l Suctionduct(Fieldsupply)
e Airoutletgrille(Fieldsupply) m Suctiongrille(Fieldsupply)
f Exhaustduct(Fieldsupply)
Names of Parts
Outdoor Unit
 •Theappearanceoftheoutdoorunitmaydifferbetweendifferentmodels.
Earth terminal (inside)
Refrigerant pipes and
inter-unit wire
Air outlet
Air inlet (back and side)
Model name
Drain hose
Wired type Wireless type
Remote controller
•Fordetailsonremotecontrolleroperation,refertothe
operationmanualincludedwiththeremotecontroller.
3 English
