16
Care and Cleaning
CAUTION
Before cleaning, be sure to stop the operation and
turn the breaker off.
Units
Indoor unit, outdoor unit and remote controller
Wipe them with dry soft cloth. 1.
Front panel
Open the front panel. 1.
Hold the front panel by the panel tabs •
on the both sides and open it.
Panel tab
Remove the front panel. 2.
Slide the front panel to either the left or •
right and pulling it toward you.
This will disconnect the front panel
shaft on one side.
Disconnect the front panel shaft on the •
other side in the same manner.
Front
panel shaft
2) Pull
2) Pull
1) Slide
1) Slide
Clean the front panel.3.
Wipe it with a soft cloth soaked in water.•
Only neutral detergent may be used.•
In case of washing the panel with water, wipe it with dry soft cloth, dry it up in the shade •
after washing.
Attach the front panel. 4.
Align the front panel shaft on the left •
and right of the front panel with the
slots, then push them all the way in.
Close the front panel slowly. •
(Press the panel at both sides and the
center.)
Front panel
shaft
Slot
CAUTION
Don’t touch the metal parts of the indoor unit. If you touch those parts, this may cause an •
injury.
When removing or attaching the front panel, use a robust and stable stool and watch your •
steps carefully.
When removing or attaching the front panel, support the panel securely with hand to prevent it •
from falling.
For cleaning, do not use hot water above 40°C, benzine, gasoline, thinner, nor other volatile •
oils, polishing compound, scrubbing brushes, nor other hand stuff.
After cleaning, make sure that the front panel is securely fi xed. •
01_EN_3P276856-1B.indb 1601_EN_3P276856-1B.indb 16 12/20/2010 4:17:28 PM12/20/2010 4:17:28 PM
