Fan Rotor / Fan Motor
Si041652EB
24
Removal Proc
edure
4
5
Pull
out and remove t
he
fan motor
stator
ASSY.
Unfasten t
he 2 hooks
and disassemble t
he
fan motor
stator
ASSY.
Step
Procedure
Points
Hook
Fan motor stator ASSY
(R23528)
Fan motor cover (body)
Bearing rubber
cushion
Fan motor stator
Rubber cushion
Fan motor
cover (cap)
(R21535)
25
27
