PCBs
Si041251EC
10
Removal Procedu
re
3.
Remove the terminal
board.
1
Remove the screw and
remove the t
erminal
board.
4.
Remove the signal
recei
ver uni
t.
1
Unfast
en the 3 hooks
and remove the si
gnal
receiv
er unit
.
2
Unfast
en the 2 hooks.
Step
Procedure
Points
Terminal board
(R4354)
(R19301)
Signal receiver unit
Hook
Hook
(R12725)
Hook
Hook
(R16033)
11
13
