Si12-411A
Outdoor Unit (50 / 52 / 58 / 68 / 75 Class)
Removal Procedure
251
2.5
Removal of
Sound Insulation
P
ro
c
ed
u
r
e
Warning
Be sur
e to wait 10 minutes
or mo
re aft
er turni
ng off al
l power suppli
es
before di
sassem
bl
ing work.
Step
Procedure
Points
1
Rem
ove 5 screws of
the ri
ght si
de panel.
2
Rem
ove 2 screws of
the part
it
ion board,
and
remove the board.
3
Remove the noise
insul
ation (
top,
outer
and inner)
.
261
263
