Air inlet
5
Read Before Operation
Names of Parts
Indoor Unit
Air outlet
Louvres (vertical blades)
• Thelouvresareinsideoftheair
outlet.
Page 13
Flaps (horizontal blades)
Page 13
Model name
plate
Indoor temperature
sensor
• Detectstheairtemperature
aroundtheunit.
Front panel
Model name
Panel tab
INTELLIGENT EYE
sensor
• Detectsthemovementsof
peopleandautomatically
switchesbetweennormal
operationandenergysaving
operation.
Page 15,16
Display
OPERATION lamp (green)
TIMER lamp (orange)
Page 19,20,23,25
INTELLIGENT EYE lamp
(green)
Page 15
Signal receiver
• Receivessignalsfromtheremote
controller.
• Whentheunitreceivesasignal,you
willhearabeepsound.
Case Sound type
Operationstart beep-beep
Settingchanged beep
Operationstop longbeep
Indoor unit ON/OFF switch
• Pressthisswitchoncetostartoperation.
Pressonceagaintostopit.
• Fortheoperationmodesetting,refertothefollowingtable.
Model Mode Temperature setting Air ow rate
HEATPUMP AUTO 25°C AUTO
COOLINGONLY COOL 22°C AUTO
• Thisswitchcanbeusedwhentheremotecontrollerismissing.
