SiENBE04-507A Troubleshooting
Service Diagnosis 115
4.4 Fan Motor (DC Motor) or Related Abnormality
Remote
Controller
Display
A6
Method of
Malfunction
Detection
The rotation speed detected by the Hall IC during fan motor operation is used to determine
abnormal fan motor operation.
Malfunction
Decision
Conditions
When the detected rotation speed is less than 50% of the H tap under maximum fan motor
rotation demand.
Supposed
Causes
 Operation halt due to short circuit inside the fan motor winding.
 Operation halt due to breaking of wire inside the fan motor.
 Operation halt due to breaking of the fan motor lead wires.
 Operation halt due to faulty capacitor of the fan motor.
 Detection error due to faulty indoor unit PCB.

Daikin FTKS25D3VMW(L) Specifications

General

Cooling Capacity	2.5 kW
Heating Capacity	3.2 kW
Power Supply	220-240V, 50Hz
Weight (Indoor Unit)	9 kg
Refrigerant	R410A
Noise Level (Outdoor Unit)	48 dB(A)
Type	Split Air Conditioner
Energy Efficiency Ratio (Cooling)	3.21 W/W
Outdoor Unit Dimensions (W x H x D)	550 x 658 x 275 mm
