Drain Pan Unit / Sw
ing Motor
Si041251EC
14
Removal Procedu
re
3.
Remove the crank
assem
bly.
1
Remove the screw of
the cr
ank assembly.
2
Unfasten the hook
and
remove the cr
ank
assembly.
The fi
gure shows the
posit
ion of
the hook when
the cr
ank assembly has
been removed.
Step
Procedure
Points
Crank
assembly
(R4382)
Hook
(R4383)
Hook
(R4384)
15
17
