English 6
If the temperature or the humidity is beyond the fol-
lowing conditions, safety devices may work and the
air conditioner may not operate, or sometimes,
water may drop from the indoor unit.
For combination with R410A outdoor unit, refer to the
following table:
Information requirements for fan coil units
INFORMATION TO IDENTIFY THE MODEL(S) TO WHICH THE
INFORMATION RELATES:
Item
Symbol Value Unit
Item
Symbol Value Unit
Cooling
capacity
(sensible)
P
rated, c
AkW
Total electric
power input
P
elec
DkW
Cooling
capacity
(latent)
P
rated, c
BkW
Sound power
level (per
speed setting if
applicable)
L
WA
EdB
Heating
capacity
P
rated, h
CkW
—
Contact
details
DAIKIN INDUSTRIES CZECH REPUBLIC s.r.o.
U Nové Hospody 1/1155, 301 00 Plzeň Skvrňany, Czech Republic
THE ABOVE TABLE RELATES TO THE MODELS AND VALUES
STATED IN THIS TABLE
Models
ABCDE
FVA125AMVEB
7.83 4.27 13.50 0.24 63
FVA140AMVEB
8.68 4.72 15.50 0.28 65
3. OPERATION RANGE
Outdoor
units
Cooling Heating
RZQG
71~140
Outdoor
temperature
-15~50°C DB
-19~21°C DB
-20~15.5°C WB
Indoor
temperature
18~37°C DB
12~28°C WB
10~27°C DB
RZQSG
71~140
Outdoor
temperature
-15~46°C DB
-14~21°C DB
-15~15.5°C WB
Indoor
temperature
20~37°C DB
14~28°C WB
10~27°C DB
RZQ
200~250
Outdoor
temperature
-5~46°C DB
-14~21°C DB
-15~15°C WB
Indoor
temperature
20~37°C DB
14~28°C WB
10~27°C DB
AZQS125
(AVA125
model only)
Outdoor
temperature
-5~46°C DB -15~15.5°C WB
Indoor
temperature
14~28°C WB 10~27°C DB
Indoor humidity ≤80%
(a)
For combination with R32 outdoor unit, refer to the
following table:
(a)
To avoid condensation and water dripping out of the
unit. If the temperature or the humidity is beyond these
conditions, safety devices may be put in action and the air
conditioner may not operate.
D
B: Dry bulb temperature
WB: Wet bulb temperature
The setting temperature range of the remote controller is
16°C to 32°C.
Regarding places for installation
• Is the air conditioner installed at a well-venti-
lated place where there are no obstacles
around?
• Do not use the air conditioner in the following
places.
a.Filled with much mineral oil such as cutting oil
b.Where there is much salt such as a beach area
c.Where sulfured gas exists such as a hot-spring
resort
d.Where there are considerable voltage fluctua-
tions such as a factory or plant
e.Vehicles and vessels
f.Where there is much spray of oil and vapor such
as a cookery, etc.
g.Where there are machines generating electro-
magnetic waves
h.Filled with acid and/or alkaline steam or vapor
• Is a snow protection measure taken?
For details, consult your dealer about snow pro-
tection hoods, etc.
Outdoor
units
Cooling Heating
RZAG
71~140
Outdoor
temperature
-20~52°C DB
-19.5~21°C DB
-20~15.5°C WB
Indoor
temperature
18~37°C DB
12~28°C WB
10~27°C DB
RZASG
71~140
Outdoor
temperature
-15~46°C DB
-14~21°C DB
-15~15.5°C WB
Indoor
temperature
20~37°C DB
14~28°C WB
10~27°C DB
AZAS125
(AVA125
model only)
Outdoor
temperature
-5~46°C DB -15~15°C WB
Indoor
temperature
14~28°C WB 10~27°C DB
Indoor humidity ≤80%
(a)
4. INSTALLATION SITE
