Engineering & Physical Data
Engineering Data - Chilled Water Fan Coil Unit (EC Motor)
Low Static Pressure (LSP)
MODEL FWC08G FWC10G FWC12G
NOMINAL COOLING CAPACITY
Btu/h 24000 30000 36000
W 7.03 8.79 10.55
NOMINAL SENSIBLE COOLING CAPACITY
Btu/h 19100 23400 27900
W 5.60 6.86 8.18
NOMINAL TOTAL INPUT POWER W 100 142 163
NOMINAL RUNNING CURRENT A 0.87 1.18 1.35
POWER SOURCE V/Ph/Hz 220-240/1/50 & 208-230/1/60
INDOOR UNIT
CONTROL
AIR DISCHARGE DUCTED
OPERATION WITHOUT CONTROLLER
AIR FLOW
HIGH CFM 800 1000 1200
MEDIUM CFM 650 805 975
LOW CFM 465 600 810
EXTERNAL STATIC PRESSURE (H/M/L) Pa 30/19/10 30/18/11 30/20/13
NOMINAL WATER FLOW RATE
USGPM 5.33 6.66 7.99
litres/min 20.18 25.22 30.26
HEAD LOSS (COOLING) kPa 38 42 38
MAX. WORKING PRESSURE kPa 1608
SURFACE AIR VELOCITY m/s 1.69 2.11 2.05
SOUND PRESSURE LEVEL (H/M/L) dBA 40/35/27 42/38/32 43/40/36
UNIT DIMENSION H X W X D mm 251x1264x461 251x1264x461 251x1514x461
PACKING DIMENSION H X W X D mm 595x1473x284 595x1473x284 595x1724x284
UNIT WEIGHT kg 26 26 29.5
CONDENSATE DRAIN SIZE mm 19.05
PIPE CONNECTION mm 19.05 BSPT FEMALE THREAD ADAPTOR
FAN
TYPE BLOWER
DRIVE DIRECT
QUANTITY 3 3 4
FAN SPEED
HIGH RPM 1140 1275 1220
MEDIUM RPM 950 1035 1010
LOW RPM 710 805 835
FAN EFFICIENCY
HIGH % 52.9 43.9 37.7
MEDIUM % 53.6 51.2 33.9
LOW % 57.6 57.3 46.7
FAN MOTOR
TYPE DC BRUSHLESS MOTOR
INDEX OF PROTECTION (IP) IP20
INSULATION GRADE B
QUANTITY 2 2 2
RATED INPUT
POWER
HIGH W 100 142 163
MEDIUM W 60 84 102
LOW W 29 40 62
RATED RUNNING
CURRENT
HIGH A 0.87 1.18 1.35
MEDIUM A 0.58 0.77 0.89
LOW A 0.37 0.42 0.60
STARTING CURRENT A 2.40 2.40 2.40
MOTOR OUTPUT W 120 120 120
MOTOR EFFICIENCY
HIGH % 80.1 81.3 80.8
MEDIUM % 77.1 78.6 79.5
LOW % 69.1 73.9 78.0
POLES 10
COIL
TUBE
MATERIAL COPPER
DIAMETER mm 7.00
FIN
MATERIAL ALUMINIUM
FACE AREA m
2
0.22 0.22 0.28
ROW 3
WATER VOLUME litre 0.90 1.04 1.29
AIR QUALITY FILTER
TYPE OPTION (WASHABLE SARANET FILTER OR ALUMINIUM MESH FILTER)
QUANTITY pc 3 3 4
CASING COLOUR WITHOUT PAINT
MODE COOLING
ENTERING AIR TEMPERATURE 27°C DB / 19°C WB
ENTERING WATER TEMPERATURE 7°C
LEAVING WATER TEMPERATURE 12°C
ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
