Engineering & Physical Data
Engineering Data - Chilled Water Fan Coil Unit
MODEL
FWKE11EH
HIGH MEDIUM LOW QUIET
NOMINAL COOLING CAPACITY
Btu/h 30700 26400 22200 17700
W 9000 7750 6500 5200
NOMINAL SENSIBLE COOLING CAPACITY
Btu/h 24500 20700 16700 13300
W 7170 6060 4900 3890
NOMINAL HEATING CAPACITY
(ENTERING WATER TEMP. = 70°C)
Btu/h 53400 46200 39100 31900
W 15650 13550 11450 9350
OMINAL TOTAL INPUT POWER W 120 83 39 23
NOMINAL RUNNING CURRENT A 1.23 0.92 0.49 0.32
POWER SOURCE V/Ph/Hz 208-230 / 1 / 60
INDOOR UNIT
CONTROL
AIR DISCHARGE 4 WAY AUTOMATIC LOUVER (UP & DOWN)
OPERATION LCD WIRELESS MICRO-COMPUTER REMOTE CONTROL
AIR FLOW CFM 1060 870 680 510
NOMINAL WATER FLOW RATE (COOLING)
USGPM 6.89 5.93 4.98 3.98
litres/min 26.09 22.47 18.84 15.07
NOMINAL WATER FLOW RATE (HEATING)
USGPM 5.99 5.19 4.38 3.58
litres/min 22.68 19.64 16.60 13.55
HEAD LOSS (COOLING) kPa 32 24 19 12
HEAD LOSS (HEATING) : 50°C kPa 52 39 30 21
MAX. WORKING PRESSURE kPa 1608
SURFACE AIR VELOCITY m/s 0.83 0.71 0.57 0.45
SOUND PRESSURE LEVEL dBA 51 46 41 34
UNIT DIMENSION - (WITH PANEL) H X W X D mm 300 X 820 X 820 ( 375 X 990 X 990)
PACKING DIMENSION - (PANEL) H X W X D mm 376 X 916 X 916 ( 125 X 1020 X 1020)
UNIT WEIGHT (UNIT + PANEL) kg 32 + 4
CONDENSATE DRAIN SIZE mm 19.05
PIPE CONNECTION mm 19.05 BSP FEMALE THREAD ADAPTOR
FAN
TYPE TURBO FAN
DRIVE DIRECT
FAN SPEED RPM 750 630 510 400
FAN MOTOR
TYPE BRUSHLESS DIRECT CURRENT
INDEX OF PROTECTION (IP) IP20
INSULATION GRADE E
RATED INPUT POWER W 120 83 39 23
RATED RUNNING CURRENT A 1.23 0.92 0.49 0.32
STARTING CURRENT A 2.2
MOTOR OUTPUT W 100
POLES 8
COIL
TUBE
MATERIAL COPPER
DIAMETER mm 7.00
FIN
MATERIAL ALUMINIUM
FACE AREA m
2
0.46
ROW 3
WATER VOLUME litre 2.35
AIR QUALITY FILTER
TYPE WASHABLE SARANET FILTER
QUANTITY pc 1
CASING COLOUR LIGHT GREY
NOTE:
A) BASED ON EUROVENT CONDITIONS
B) ADDITIONAL 10W IS REQUIRED FOR CONDENSATE DRAIN PUMP
C) SOUND PRESSURE LEVEL IS TESTED AS PER JIS STANDARD AS BELOW:
FWKE05E(H) MODEL - 1.4M BELOW THE FACE CENTER OF AIR RETURN OF THE UNIT
FWKE08/11E(H) MODEL - 1.5M BELOW THE FACE CENTER OF AIR RETURN OF THE UNIT
MODE COOLING HEATING
ENTERING AIR TEMPERATURE 27°C DB / 19°C WB 20°C DB
ENTERING WATER TEMPERATURE 7°C
50°C (2 Pipes System)
70°C (4 Pipes System)
LEAVING WATER TEMPERATURE 12°C 60°C (4 Pipes System)
ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
