SiE74-202 Removal Procedure of MC401VE
Removal Procedure 29
3Disengage hooks located
at four corners of the filter
to remove prefilter
located at rear side of the
front panel.
4 Hold the ion filter (roll)
case by the left and right
side handles, and lift
upward and out.
5 Main components
Step Procedure Points
