Photocatalytic Air Purifiers 53
SiBE81-623A Removal Procedure
Procedure Points
(2) Pull out the electrical
box to detach.
* When assembling, fit the
box in the groove.
3. Removing the PCB
(1) Undo the 2 hooks at
the back and take out
the flame-proof plate.
* When fitting the flame-
proof plate in position,
be careful not to confuse
the inserting positions.
Flame-proof plate
To Next Page
