Page #4 background image
2xD
D
2xD
3xD
D D
3xD
D
4
1
Correct distance
MODULAR T
PRO
MODULAR T
SMART
PRE
HEATING
PRE
HEATING
POST
HEATING
Electric coil
Electric coil
Electric coil
Suggested
distance
beetween
probe and coil
Suggested
distance
beetween
probe and coil
Suggested
distance
beetween
probe and coil
Suggested
distance
beetween coil
and unit
Suggested
distance
beetween coil
and unit
Probe
Probe
Probe
D* = diameter of ducts
(e.g. if D= 250 mm 1xD= 250 mm, 2xD = 500 mm....)
