Daikin Modular T - Probe Installation (PRE-HEATING)

ø10mm
ø5mm
ø5mm
1
2
3
4
Not
provided
3xD
3xD
D
D
Connection of PRE-HEATING probe
9
8
Installation of probe (PRE-HEATING)
Connect the
probe according
to the supplied
wiring diagram
Modular T Smart version only
Electric pre/post
heating coil
Suggested
distance
beetween probe
and coil
Pre-heating probe
