Figure 35: DPSA Unit Service Clearances (Scenario A)
Figure 36: DPSA Unit Service Clearances (Scenario B)
60”
72”
60”
60”
96”
Return
Section
Filter section
Supply Fan Section
To roof
access
location
Recommended
roof walkway
Heat Section
Condenser Section
48”
48”
48”
72”
To roof
access
location
Recommended
roof walkway
96”
Return
Section
Filter section
Supply Fan Section
Heat Section
Condenser Section
