Introduction
This manual provides installation information about the Rebel
Applied rooftop unit - model DPSA. In addition to an overall
description of the unit, it includes mechanical and electrical
installation and start-up procedures. For operations and/or
maintenance procedures, see OM 1373.
Table 1: Program Specic Rooftop Unit Literature
Product Manual Title Manual Number
Rebel Applied- model
DPSA
Unit Installation and
Start Up
IM 1287
Unit Operation OM 1373
Non-Daikin Applied See vendor manuals
Nameplate Information
Unit Nameplate
The unit nameplate is located on the outside lower right
corner on the main control box door. It includes the unit
model number, serial number, unit part number, electrical
characteristics, and refrigerant charge.
Compressor Nameplate
On units that utilize the tandem or trio compressor design,
each compressor includes an individual nameplate.
Electric Heater Nameplate
On units that include electric heat, the cabinet electric heater
nameplate is located next to the electric heater access door.
The electric heater rating plate is included on the electric
heater; this includes the electric heater model number.
Fusing
The use of properly sized time delay fuses, in accordance with
nameplate data, is permitted for this unit.
Hazardous Information Messages
DANGER
Danger indicates a hazardous situation, which will result in death or serious
injury if not avoided.
WARNING
Warning indicates a potentially hazardous situations, which can result in
property damage, personal injury, or death if not avoided.
CAUTION
Caution indicates a potentially hazardous situations, which can result in
minor injury or equipment damage if not avoided.
NOTICE
Notice indicates practices not related to physical injury.
NOTE: Indicates important details or clarifying statements for
information presented.
